The University of Wisconsin-Madison is a public land-grant research university in Madison, Wisconsin, and one of the very few institutions in this cohort that genuinely operates an API program of its own rather than pointing at a vendor's. Its Division of Information Technology (DoIT) runs a formal API Program on a UW-owned Google Apigee organization (doit-ipt-apigee-prod-ce29), fronted by a public developer portal at developer.wisc.edu, and publishes eleven OpenAPI 3.0 contracts — 245 operations across Person, HR, Manifest (Grouper groups), Finance, Locations, Enterprise Billing and OAuth — every one of them served from api.wisc.edu or mock.api.wisc.edu with a wisc.edu contact. Nothing in this repository is a vendor contract running under the institution's name: there is no Figshare, Pure, Ex Libris, Dataverse or Symplectic surface attributed here. Beyond the gateway, UW-Madison operates a fully public unauthenticated course-search API at public.enroll.wisc.edu, its own Shibboleth identity provider at login.wisc.edu speaking both SAML 2.0 and OpenID Connect, and a live OAI-PMH 2.0 endpoint for the MINDS@UW institutional repository. The honest limits: production access is gated behind a manual institutional approval per API product and is effectively closed to anyone without a UW NetID, the estate declares zero OAuth scopes, no contract carries a license or terms of service, and the developer portal is a client-rendered single-page app that returns an identical 2,138-byte shell for every URL — including ones that do not exist. Learning management runs on a Canvas tenant, recorded here as a tenant relationship and not as UW-Madison engineering.
University of Wisconsin-Madison publishes 12 APIs on the APIs.io network, including Person API, Mock Person API, Mock Person API (Certificates), and 9 more. Tagged areas include University, Higher Education, Education, Public Research University, and United States.
The University of Wisconsin-Madison catalog on APIs.io includes 1 JSON-LD context and 1 Spectral governance ruleset.
University of Wisconsin-Madison’s developer surface includes documentation, authentication, status page, support, engineering blog, and 28 more developer resources.
UniversityHigher EducationEducationPublic Research UniversityUnited StatesWisconsinBig TenAssociation of American UniversitiesIdentityIdentity FederationCourse CatalogResearch RepositoryStudent Information SystemHuman ResourcesFinanceCurriculum
Regulatory Posture applies to this provider. Its tags matched the
Education & Research regime, so
Regulatory Posture carries 15 points of the composite.
If this regime is wrong for your business, say so on your
provider repo — the
applicability map is public and we will correct it.
The six quality facets above are damped to 85 points between them,
because the conditional facet above carries the other
15. That is why each facet's contribution is shown against a damped
maximum: raising a quality facet moves the composite by 85% of its nominal
weight, not 100%. The full arithmetic is at apis.io/rating/.
Authoritative person and identity data for UW-Madison — names, populations, affiliations, contact points, exports and webhooks. 47 operations over 31 paths, JSON:API envelopes, ...
Openly published mock of the Person API on mock.api.wisc.edu, mirroring all 47 operations so the contract and data shape are public even though production data is not. An unusua...
Certificate-authentication variant of the Mock Person API — 39 operations over 23 paths, published for testing the mTLS/certificate access path documented on the portal.
Group and membership data for UW-Madison's Manifest service, backed by Internet2 Grouper Web Services. 5 operations, JSON:API, OAuth 2.0 client credentials, manual approval. Tog...
The largest contract in the estate — 73 operations covering sponsored research and financial administration: awards, award lines and tasks, grants, gifts, funds, cost centers, b...
Campus location, building and room reference data. 3 operations, OAuth 2.0 client credentials, maintained by the DoIT EBS/IBS API team (locations-api@doit.wisc.edu).
Service-provider billing transaction submission and lookup, backed by Salesforce. 7 operations. Recorded as published, with a defect noted honestly: the contract listed in the P...
The token endpoint for the whole gateway — POST https://api.wisc.edu/oauth/token, HTTP Basic presentation of client_id/client_secret, returning the bearer access token every oth...
UW-Madison's only openly callable API — the unauthenticated JSON search behind public.enroll.wisc.edu/search. Verified live on 2026-08-19: GET /terms returns the open term codes...
Institution-operated Shibboleth IdP at login.wisc.edu, machine-readable on two protocols and almost never catalogued for a university. https://login.wisc.edu/idp/shibboleth retu...
UW-Madison's curricular data model (v1.5), published as generated Javadoc-style reference documentation on the DoIT WAMS host. Verified live and genuinely institution-operated, ...
UW-Madison's learning management system runs on an Instructure Canvas tenant at canvas.wisc.edu, gated behind the institution's own Shibboleth IdP — an unauthenticated request 3...
aid: university-of-wisconsin-madison
name: University of Wisconsin-Madison
x-type: university
x-category: Public Research University
description: 'The University of Wisconsin-Madison is a public land-grant research university in Madison, Wisconsin, and one
of the very few institutions in this cohort that genuinely operates an API program of its own rather than pointing at a
vendor''s. Its Division of Information Technology (DoIT) runs a formal API Program on a UW-owned Google Apigee organization
(doit-ipt-apigee-prod-ce29), fronted by a public developer portal at developer.wisc.edu, and publishes eleven OpenAPI 3.0
contracts — 245 operations across Person, HR, Manifest (Grouper groups), Finance, Locations, Enterprise Billing and OAuth
— every one of them served from api.wisc.edu or mock.api.wisc.edu with a wisc.edu contact. Nothing in this repository is
a vendor contract running under the institution''s name: there is no Figshare, Pure, Ex Libris, Dataverse or Symplectic
surface attributed here. Beyond the gateway, UW-Madison operates a fully public unauthenticated course-search API at public.enroll.wisc.edu,
its own Shibboleth identity provider at login.wisc.edu speaking both SAML 2.0 and OpenID Connect, and a live OAI-PMH 2.0
endpoint for the MINDS@UW institutional repository. The honest limits: production access is gated behind a manual institutional
approval per API product and is effectively closed to anyone without a UW NetID, the estate declares zero OAuth scopes,
no contract carries a license or terms of service, and the developer portal is a client-rendered single-page app that returns
an identical 2,138-byte shell for every URL — including ones that do not exist. Learning management runs on a Canvas tenant,
recorded here as a tenant relationship and not as UW-Madison engineering.'
type: Index
accessModel:
pricing: free
onboarding: request
trial: false
try_now: false
public: false
label: Free
confidence: high
source:
- openapi
- plans
generated: '2026-08-19'
method: probed
position: Producer
access: 1st-Party
image: https://kinlane-images.s3.amazonaws.com/shared/apis-json/icons/university-of-wisconsin-madison.png
url: https://raw.githubusercontent.com/api-evangelist/university-of-wisconsin-madison/refs/heads/main/apis.yml
tags:
- University
- Higher Education
- Education
- Public Research University
- United States
- Wisconsin
- Big Ten
- Association of American Universities
- Identity
- Identity Federation
- Course Catalog
- Research Repository
- Student Information System
- Human Resources
- Finance
- Curriculum
created: '2026-06-03'
modified: '2026-08-19'
specificationVersion: '0.23'
x-coverage:
state: covered
reason: institution-operated-program-verified
detail: 'UW-Madison is not a thin profile. Twelve machine-readable contracts were retrieved and every one was checked against
the operator axis before being saved: all eleven portal specs declare servers under api.wisc.edu / mock.api.wisc.edu /
doit.dev.api.wisc.edu and DoIT contacts, so all are x-operator institution. No vendor-attributed contract was found or
added. Three findings limit the profile. (1) The developer portal at developer.wisc.edu is an Angular SPA that returns
an identical 2,138-byte shell with HTTP 200 for EVERY path — a bogus URL and /.well-known/security.txt both return the
same body — so no developer.wisc.edu deep link can be verified by status code; the pointers kept here were confirmed instead
against the portal''s own sitemap.xml, and the previously catalogued DARS API pointer was removed because it appears in
neither the sitemap nor the portal''s API catalog. The contracts themselves were recovered from the portal''s own JSON
API (/portals/api/sites/{siteId}/liveportal/apis/{apiId}/download_spec), not from the rendered pages. (2) Production APIs
are gated: every API product carries approvalType "manual" and a UW NetID is required to sign in, so request/response
behaviour could not be exercised — though UW-Madison publishes open mock variants on mock.api.wisc.edu, which is why the
contracts are still fully readable. (3) No OpenAPI exists for the course-search API, the identity federation or the OAI-PMH
endpoint; those were probed live and are recorded with method probed, never as UW-Madison publications.'
evidence:
- url: https://developer.wisc.edu/portals/api/sites/doit-ipt-apigee-prod-ce29-productionorgportal/liveportal/apis
status: 200
- url: https://developer.wisc.edu/sitemap.xml
status: 200
- url: https://developer.wisc.edu/docs/dars/1/types/DarsBatchAuditRequest
status: 200
note: soft-404 — byte-identical 2,138-byte SPA shell, same as a deliberately bogus URL
- url: https://api.wisc.edu/
status: 404
note: gateway root, not a portal — expected
- url: https://public.enroll.wisc.edu/api/search/v1/terms
status: 200
- url: https://public.enroll.wisc.edu/api/search/v1/aggregate
status: 200
- url: https://login.wisc.edu/idp/shibboleth
status: 200
- url: https://login.wisc.edu/.well-known/openid-configuration
status: 200
- url: https://minds.wisc.edu/server/oai/request?verb=Identify
status: 200
- url: https://www.wisc.edu/llms.txt
status: 404
- url: https://www.wisc.edu/.well-known/security.txt
status: 404
checked: '2026-08-19'
apis:
- aid: university-of-wisconsin-madison:person-api
name: Person API
x-operator: institution
description: 'Authoritative person and identity data for UW-Madison — names, populations, affiliations, contact points,
exports and webhooks. 47 operations over 31 paths, JSON:API envelopes, OAuth 2.0 client credentials. Gated: production
access requires an approved institutional request. This is the closest thing in the estate to SCIM, expressed in UW-local
terms.'
humanURL: https://developer.wisc.edu/person-api
baseURL: https://api.wisc.edu
tags:
- Identity
- People
- Directory
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-person-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-person-api-schema.json
- type: Signup
url: https://developer.wisc.edu/person-api/getting-access
- aid: university-of-wisconsin-madison:mock-person-api
name: Mock Person API
x-operator: institution
description: Openly published mock of the Person API on mock.api.wisc.edu, mirroring all 47 operations so the contract and
data shape are public even though production data is not. An unusually good practice for an institution of this cohort.
baseURL: https://mock.api.wisc.edu
tags:
- Identity
- Mock
- Sandbox
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-mock-person-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-mock-person-api-schema.json
- aid: university-of-wisconsin-madison:mock-person-api-certificates
name: Mock Person API (Certificates)
x-operator: institution
description: Certificate-authentication variant of the Mock Person API — 39 operations over 23 paths, published for testing
the mTLS/certificate access path documented on the portal.
baseURL: https://mock.api.wisc.edu
tags:
- Identity
- Mock
- Certificates
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-mock-person-api-certificates-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-mock-person-api-certificates-schema.json
- aid: university-of-wisconsin-madison:hr-api
name: HR API
x-operator: institution
description: Institutional HR data — academic units, supervisory organizations, job profiles, positions and full-time-equivalent
data, surfacing Workday-derived concepts under UW-Madison's own JSON:API contract. 9 operations, OAuth 2.0 client credentials,
gated.
humanURL: https://developer.wisc.edu/hr-api/supervisory-organizations
baseURL: https://api.wisc.edu/hr
tags:
- Human Resources
- Academic Units
- Workforce
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-hr-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-hr-api-schema.json
- type: ChangeLog
url: https://developer.wisc.edu/hr-api/release-notes
- aid: university-of-wisconsin-madison:mock-hr-api
name: Mock HR API
x-operator: institution
description: Openly published mock of the HR API on mock.api.wisc.edu, mirroring all 9 operations.
baseURL: https://mock.api.wisc.edu/hr
tags:
- Human Resources
- Mock
- Sandbox
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-mock-hr-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-mock-hr-api-schema.json
- aid: university-of-wisconsin-madison:manifest-api
name: Manifest API
x-operator: institution
description: Group and membership data for UW-Madison's Manifest service, backed by Internet2 Grouper Web Services. 5 operations,
JSON:API, OAuth 2.0 client credentials, manual approval. Together with the Person API this is UW-Madison's authorization
substrate.
baseURL: https://api.wisc.edu/manifest
tags:
- Identity
- Group
- Authorization
tags_raw:
- Identity
- Groups
- Authorization
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-manifest-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-manifest-api-schema.json
- aid: university-of-wisconsin-madison:mock-manifest-api
name: Mock Manifest API
x-operator: institution
description: Openly published mock of the Manifest API on mock.api.wisc.edu.
baseURL: https://mock.api.wisc.edu/manifest
tags:
- Identity
- Group
- Mock
tags_raw:
- Identity
- Groups
- Mock
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-mock-manifest-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-mock-manifest-api-schema.json
- aid: university-of-wisconsin-madison:finance-api
name: Finance API
x-operator: institution
description: 'The largest contract in the estate — 73 operations covering sponsored research and financial administration:
awards, award lines and tasks, grants, gifts, funds, cost centers, budget lines, billing schedules, customer invoices,
expense reports and assets. Built by the DoIT Enterprise Business Systems (EBS) Integrated Business Solutions team. OpenAPI
3.0.4, OAuth 2.0 client credentials, gated.'
baseURL: https://api.wisc.edu/finance
tags:
- Finance
- Grants
- Sponsored Research
- Procurement
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-finance-api-openapi.yml
- aid: university-of-wisconsin-madison:locations-api
name: Locations API
x-operator: institution
description: Campus location, building and room reference data. 3 operations, OAuth 2.0 client credentials, maintained by
the DoIT EBS/IBS API team (locations-api@doit.wisc.edu).
baseURL: https://api.wisc.edu
tags:
- Locations
- Buildings
- Campus
- Reference Data
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-locations-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-locations-api-schema.json
- aid: university-of-wisconsin-madison:enterprise-billing-api
name: Enterprise Billing API
x-operator: institution
description: 'Service-provider billing transaction submission and lookup, backed by Salesforce. 7 operations. Recorded as
published, with a defect noted honestly: the contract listed in the PRODUCTION portal declares only a development server
(https://doit.dev.api.wisc.edu/enterprise-billing) and declares no security scheme, despite the API product carrying manual
approval.'
baseURL: https://doit.dev.api.wisc.edu/enterprise-billing
tags:
- Billing
- Finance
- Salesforce
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-enterprise-billing-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-enterprise-billing-api-schema.json
- aid: university-of-wisconsin-madison:oauth-api
name: OAuth API
x-operator: institution
description: The token endpoint for the whole gateway — POST https://api.wisc.edu/oauth/token, HTTP Basic presentation of
client_id/client_secret, returning the bearer access token every other UW-Madison API requires. Declares no scopes.
baseURL: https://api.wisc.edu/oauth
tags:
- Authentication
- Security
tags_raw:
- Authentication
- OAuth
- Security
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-oauth-api-openapi.yml
- type: Authentication
url: authentication/university-of-wisconsin-madison-authentication.yml
- aid: university-of-wisconsin-madison:course-search-api
name: Public Course Search API
x-operator: institution
description: 'UW-Madison''s only openly callable API — the unauthenticated JSON search behind public.enroll.wisc.edu/search.
Verified live on 2026-08-19: GET /terms returns the open term codes, GET /aggregate returns 190 subject facets per term,
and a POST search returned 226 and 932 course records for two terms. No credential of any kind is required. The OpenAPI
here is PROBED, not published by UW-Madison.'
humanURL: https://public.enroll.wisc.edu/search
baseURL: https://public.enroll.wisc.edu/api/search/v1
tags:
- Course Catalog
- Curriculum
- Registrar
- Open Access
properties:
- type: OpenAPI
url: openapi/university-of-wisconsin-madison-course-search-api-openapi.yml
- type: JSONSchema
url: json-schema/university-of-wisconsin-madison-course-search-api-schema.json
- type: Examples
url: examples/university-of-wisconsin-madison-course-search-search-example.json
- aid: university-of-wisconsin-madison:identity-federation
name: UW-Madison Identity Provider (Shibboleth)
x-operator: institution
description: Institution-operated Shibboleth IdP at login.wisc.edu, machine-readable on two protocols and almost never catalogued
for a university. https://login.wisc.edu/idp/shibboleth returns SAML 2.0 metadata (entityID https://login.wisc.edu/idp/shibboleth,
shibmd:Scope wisc.edu, signing and encryption keys), and https://login.wisc.edu/.well-known/openid-configuration returns
a full OIDC discovery document. This governs campus SSO and the vendor tenants — it is NOT the API gateway, which uses
OAuth 2.0 client credentials and publishes no discovery document.
humanURL: https://login.wisc.edu/
baseURL: https://login.wisc.edu
tags:
- Identity Federation
- SAML
- Shibboleth
- OpenID Connect
- Single Sign-On
properties:
- type: SAMLMetadata
url: https://login.wisc.edu/idp/shibboleth
- type: OpenIDConnectDiscovery
url: https://login.wisc.edu/.well-known/openid-configuration
- type: Conformance
url: conformance/university-of-wisconsin-madison-conformance.yml
- aid: university-of-wisconsin-madison:minds-oai-pmh
name: MINDS@UW OAI-PMH Endpoint
x-operator: institution
description: Live OAI-PMH 2.0 harvesting endpoint for MINDS@UW, UW-Madison's institutional repository. Confirmed with ?verb=Identify
— repositoryName 'MINDS@UW', protocolVersion 2.0, adminEmail dspace-help@library.wisc.edu, records back to 1985 — and
?verb=ListMetadataFormats, which offers 13 prefixes (oai_dc, qdc, dim, xoai, mods, mets, didl, ore, rdf, marc, etdms,
rioxx, uketd_dc). Classed institution rather than tenant because the endpoint reports its own baseURL under wisc.edu and
is administered by UW-Madison Libraries; the underlying DSpace software is open source and self-hosted, not a vendor SaaS
contract.
humanURL: https://minds.wisc.edu/
baseURL: https://minds.wisc.edu/server/oai/request
tags:
- Research Repository
- OAI-PMH
- Libraries
- Open Access
- Metadata
properties:
- type: APIReference
url: https://minds.wisc.edu/server/oai/request?verb=Identify
- type: Conformance
url: conformance/university-of-wisconsin-madison-conformance.yml
- aid: university-of-wisconsin-madison:curricular-data-model
name: Curricular Data Model
x-operator: institution
description: UW-Madison's curricular data model (v1.5), published as generated Javadoc-style reference documentation on
the DoIT WAMS host. Verified live and genuinely institution-operated, but it is reference documentation for a Java data
model — there is no OpenAPI and no callable endpoint behind it, so no contract is saved.
humanURL: https://wams.doit.wisc.edu/chub/curricular-data-model-1.5/apidocs/index.html
tags:
- Curriculum
- Courses
- Data Model
- Documentation
properties:
- type: Documentation
url: https://wams.doit.wisc.edu/chub/curricular-data-model-1.5/apidocs/index.html
- aid: university-of-wisconsin-madison:canvas-lms
name: Canvas LMS (tenant)
x-operator: tenant
description: UW-Madison's learning management system runs on an Instructure Canvas tenant at canvas.wisc.edu, gated behind
the institution's own Shibboleth IdP — an unauthenticated request 302-redirects to login.wisc.edu/idp/profile/SAML2/Redirect/SSO,
and canvas.wisc.edu/api/v1/accounts returns Canvas's own 401 JSON. This is a REAL institutional fact and one of UW-Madison's
largest programmable surfaces, so it is recorded — but the data is UW-Madison's and the contract is Instructure's. Per
the operator axis, Instructure's generic Canvas API specification is deliberately NOT saved under this institution, and
no artifact is derived from it. Any LTI conformance at UW-Madison lives here, inside the vendor's contract, not in anything
the institution publishes.
humanURL: https://canvas.wisc.edu/
baseURL: https://canvas.wisc.edu/api/v1
tags:
- Learning Management
- Canvas
- Instructure
- Tenant
- LTI
properties:
- type: Website
url: https://canvas.wisc.edu/
common:
- type: Website
url: https://www.wisc.edu/
- type: DeveloperPortal
url: https://developer.wisc.edu/
- type: Documentation
url: https://kb.wisc.edu/uw-apis/
- type: SourceCode
url: https://git.doit.wisc.edu/interop/external-docs/api-publisher-documentation
- type: Authentication
url: authentication/university-of-wisconsin-madison-authentication.yml
- type: Scopes
url: scopes/university-of-wisconsin-madison-scopes.yml
- type: Errors
url: errors/university-of-wisconsin-madison-errors.yml
- type: Lifecycle
url: lifecycle/university-of-wisconsin-madison-lifecycle.yml
- type: Conformance
url: conformance/university-of-wisconsin-madison-conformance.yml
- type: Rules
url: rules/university-of-wisconsin-madison-rules.yml
- type: Vocabulary
url: vocabulary/university-of-wisconsin-madison-vocabulary.yml
- type: JSONLD
url: json-ld/university-of-wisconsin-madison-context.jsonld
- type: IdentityFederation
url: https://login.wisc.edu/idp/shibboleth
- type: CourseCatalog
url: https://public.enroll.wisc.edu/search
- type: ResearchRepository
url: https://minds.wisc.edu/
- type: LibraryCatalog
url: https://search.library.wisc.edu/
- type: ResearchComputing
url: https://chtc.cs.wisc.edu/
- type: OpenData
url: https://data.wisc.edu/
- type: AIPolicy
url: https://it.wisc.edu/ai/generative-ai-uw-madison-use-policies/
- type: AITooling
url: https://it.wisc.edu/ai/
- type: GitHubOrganization
url: https://github.com/UW-Madison-DoIT
- type: PrivacyPolicy
url: https://www.wisc.edu/privacy-notice/
- type: TermsOfService
url: https://policy.wisc.edu/
- type: Status
url: https://outages.doit.wisc.edu/
- type: Support
url: https://kb.wisc.edu/
- type: Blog
url: https://news.wisc.edu/
- type: LinkedIn
url: https://www.linkedin.com/school/uw-madison/
- type: Twitter
url: https://twitter.com/UWMadison
- type: DomainSecurity
url: security/university-of-wisconsin-madison-domain-security.yml
- type: Plans
url: plans/university-of-wisconsin-madison-plans-pricing.yml
- type: RateLimits
url: rate-limits/university-of-wisconsin-madison-rate-limits.yml
- type: FinOps
url: finops/university-of-wisconsin-madison-finops.yml
- type: Review
url: review.yml
maintainers:
- FN: Kin Lane
email: kin@apievangelist.com
Kin Score
How this is scored →
