Juniper Networks

opencollection: 1.0.0
info:
  name: Juniper Networks Juniper vSRX REST API
  version: '23.4'
request:
  auth:
    type: basic
    username: '{{username}}'
    password: '{{password}}'
items:
- info:
    name: Configuration
    type: folder
  items:
  - info:
      name: Juniper Networks Get device configuration
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/configuration
      params:
      - name: type
        value: ''
        type: query
        description: Configuration database to read.
      - name: path
        value: ''
        type: query
        description: 'Configuration hierarchy path to filter. Example: security/policies to return only security policy configuration.'
    docs: Returns the current candidate or committed Junos configuration in JSON or XML format. Supports filtering by configuration
      hierarchy path.
  - info:
      name: Juniper Networks Update configuration
      type: http
    http:
      method: PUT
      url: https://{vsrx_host}/api/v1/configuration
      body:
        type: json
        data: '{}'
    docs: Applies configuration changes to the candidate configuration. Changes must be committed separately to take effect.
  - info:
      name: Juniper Networks Commit configuration
      type: http
    http:
      method: POST
      url: https://{vsrx_host}/api/v1/configuration/commit
      body:
        type: json
        data: '{}'
    docs: Commits the candidate configuration to the active running configuration. Supports commit check, commit confirm with
      rollback timer, and commit comments.
- info:
    name: Security Policies
    type: folder
  items:
  - info:
      name: Juniper Networks List security policies
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/security/policies
    docs: Returns all security policies configured on the vSRX. Policies are organized by from-zone to-zone pairs and evaluated
      top-down.
  - info:
      name: Juniper Networks List security zones
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/security/zones
    docs: Returns all security zones configured on the vSRX. Zones are logical groupings of interfaces that define trust boundaries
      for policy enforcement.
- info:
    name: NAT
    type: folder
  items:
  - info:
      name: Juniper Networks List source NAT rules
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/security/nat/source
    docs: Returns all source NAT rule sets and rules. Source NAT translates the source IP address of outbound traffic for
      internet access or address hiding.
  - info:
      name: Juniper Networks List destination NAT rules
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/security/nat/destination
    docs: Returns all destination NAT rule sets and rules. Destination NAT translates destination addresses for inbound traffic
      to internal server addresses.
- info:
    name: VPN
    type: folder
  items:
  - info:
      name: Juniper Networks List IPsec VPN tunnels
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/security/ipsec/vpn
    docs: Returns all IPsec VPN tunnel configurations, including IKE gateway associations, encryption settings, and tunnel
      status.
- info:
    name: Monitoring
    type: folder
  items:
  - info:
      name: Juniper Networks List active flow sessions
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/monitoring/security/flow/session
      params:
      - name: source_prefix
        value: ''
        type: query
        description: Filter by source IP prefix.
      - name: destination_prefix
        value: ''
        type: query
        description: Filter by destination IP prefix.
      - name: application
        value: ''
        type: query
        description: Filter by application name.
    docs: Returns currently active security flow sessions on the vSRX. Equivalent to the show security flow session CLI command.
- info:
    name: System
    type: folder
  items:
  - info:
      name: Juniper Networks Get system information
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/system/information
    docs: Returns system information including hostname, model, Junos version, serial number, and uptime.
  - info:
      name: Juniper Networks List system alarms
      type: http
    http:
      method: GET
      url: https://{vsrx_host}/api/v1/system/alarms
    docs: Returns active system alarms on the vSRX.
bundled: true
