opencollection: 1.0.0
info:
  name: Supermicro Redfish API
  version: '1.0'
request:
  auth:
    type: basic
    username: '{{username}}'
    password: '{{password}}'
items:
- info:
    name: Service Root
    type: folder
  items:
  - info:
      name: Get Service Root
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/
    docs: Returns the service root resource containing links to all top-level collections.
- info:
    name: Systems
    type: folder
  items:
  - info:
      name: List Computer Systems
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Systems
    docs: Returns the collection of computer systems managed by this BMC.
  - info:
      name: Get Computer System
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Systems/:systemId
      params:
      - name: systemId
        value: ''
        type: path
        description: Unique identifier for the computer system
    docs: Returns detailed information about a specific computer system including CPU, memory, and health status.
  - info:
      name: Update Computer System
      type: http
    http:
      method: PATCH
      url: https://{bmc-ip}/redfish/v1/Systems/:systemId
      params:
      - name: systemId
        value: ''
        type: path
        description: Unique identifier for the computer system
      body:
        type: json
        data: '{}'
    docs: Updates properties of a specific computer system such as boot order or asset tag.
  - info:
      name: Reset Computer System
      type: http
    http:
      method: POST
      url: https://{bmc-ip}/redfish/v1/Systems/:systemId/Actions/ComputerSystem.Reset
      params:
      - name: systemId
        value: ''
        type: path
        description: Unique identifier for the computer system
      body:
        type: json
        data: '{}'
    docs: Performs a reset action on the computer system (power on, off, restart, etc.).
  - info:
      name: List Processors
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Systems/:systemId/Processors
      params:
      - name: systemId
        value: ''
        type: path
    docs: Returns the collection of processors in the computer system.
  - info:
      name: List Memory Modules
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Systems/:systemId/Memory
      params:
      - name: systemId
        value: ''
        type: path
    docs: Returns the collection of memory modules in the computer system.
- info:
    name: Storage
    type: folder
  items:
  - info:
      name: List Storage Controllers
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Systems/:systemId/Storage
      params:
      - name: systemId
        value: ''
        type: path
    docs: Returns the collection of storage controllers in the computer system.
  - info:
      name: Get Storage Controller
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Systems/:systemId/Storage/:storageId
      params:
      - name: systemId
        value: ''
        type: path
      - name: storageId
        value: ''
        type: path
    docs: Returns detailed information about a specific storage controller.
- info:
    name: Network
    type: folder
  items:
  - info:
      name: List Ethernet Interfaces
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Systems/:systemId/EthernetInterfaces
      params:
      - name: systemId
        value: ''
        type: path
    docs: Returns the collection of network interfaces in the computer system.
- info:
    name: Chassis
    type: folder
  items:
  - info:
      name: List Chassis
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Chassis
    docs: Returns the collection of chassis managed by this BMC.
  - info:
      name: Get Chassis
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Chassis/:chassisId
      params:
      - name: chassisId
        value: ''
        type: path
        description: Unique identifier for the chassis
    docs: Returns detailed information about a specific chassis including power and thermal data.
  - info:
      name: Get Chassis Power
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Chassis/:chassisId/Power
      params:
      - name: chassisId
        value: ''
        type: path
    docs: Returns power supply status, power consumption readings, and power control settings.
  - info:
      name: Get Chassis Thermal
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Chassis/:chassisId/Thermal
      params:
      - name: chassisId
        value: ''
        type: path
    docs: Returns temperature sensor readings and fan speed data for the chassis.
- info:
    name: Managers
    type: folder
  items:
  - info:
      name: List Managers
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Managers
    docs: Returns the collection of management controllers (BMCs) available.
  - info:
      name: Get Manager
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/Managers/:managerId
      params:
      - name: managerId
        value: ''
        type: path
        description: Unique identifier for the manager
    docs: Returns detailed information about a specific BMC manager including firmware version and network settings.
  - info:
      name: Update Manager
      type: http
    http:
      method: PATCH
      url: https://{bmc-ip}/redfish/v1/Managers/:managerId
      params:
      - name: managerId
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Updates properties of the BMC manager such as network configuration or time settings.
  - info:
      name: Reset Manager
      type: http
    http:
      method: POST
      url: https://{bmc-ip}/redfish/v1/Managers/:managerId/Actions/Manager.Reset
      params:
      - name: managerId
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Resets the BMC manager (restarts the BMC).
- info:
    name: Sessions
    type: folder
  items:
  - info:
      name: List Sessions
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/SessionService/Sessions
    docs: Returns all active Redfish sessions.
  - info:
      name: Create Session
      type: http
    http:
      method: POST
      url: https://{bmc-ip}/redfish/v1/SessionService/Sessions
      body:
        type: json
        data: '{}'
    docs: Creates a new Redfish session for authentication. Returns an auth token in the X-Auth-Token header.
  - info:
      name: Get Session
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/SessionService/Sessions/:sessionId
      params:
      - name: sessionId
        value: ''
        type: path
    docs: Returns details about a specific active session.
  - info:
      name: Delete Session
      type: http
    http:
      method: DELETE
      url: https://{bmc-ip}/redfish/v1/SessionService/Sessions/:sessionId
      params:
      - name: sessionId
        value: ''
        type: path
    docs: Deletes (logs out) a specific Redfish session.
- info:
    name: Accounts
    type: folder
  items:
  - info:
      name: List Accounts
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/AccountService/Accounts
    docs: Returns all user accounts configured on the BMC.
  - info:
      name: Create Account
      type: http
    http:
      method: POST
      url: https://{bmc-ip}/redfish/v1/AccountService/Accounts
      body:
        type: json
        data: '{}'
    docs: Creates a new user account on the BMC.
  - info:
      name: Get Account
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/AccountService/Accounts/:accountId
      params:
      - name: accountId
        value: ''
        type: path
    docs: Returns details about a specific user account.
  - info:
      name: Update Account
      type: http
    http:
      method: PATCH
      url: https://{bmc-ip}/redfish/v1/AccountService/Accounts/:accountId
      params:
      - name: accountId
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Updates properties of a user account such as password or role.
  - info:
      name: Delete Account
      type: http
    http:
      method: DELETE
      url: https://{bmc-ip}/redfish/v1/AccountService/Accounts/:accountId
      params:
      - name: accountId
        value: ''
        type: path
    docs: Deletes a user account from the BMC.
- info:
    name: Event Service
    type: folder
  items:
  - info:
      name: Get Event Service
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/EventService
    docs: Returns the event service resource with subscription management capabilities.
  - info:
      name: List Event Subscriptions
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/EventService/Subscriptions
    docs: Returns all event subscriptions configured for this BMC.
  - info:
      name: Create Event Subscription
      type: http
    http:
      method: POST
      url: https://{bmc-ip}/redfish/v1/EventService/Subscriptions
      body:
        type: json
        data: '{}'
    docs: Creates a new event subscription to receive server event notifications via webhook.
  - info:
      name: Get Event Subscription
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/EventService/Subscriptions/:subscriptionId
      params:
      - name: subscriptionId
        value: ''
        type: path
    docs: Returns details about a specific event subscription.
  - info:
      name: Delete Event Subscription
      type: http
    http:
      method: DELETE
      url: https://{bmc-ip}/redfish/v1/EventService/Subscriptions/:subscriptionId
      params:
      - name: subscriptionId
        value: ''
        type: path
    docs: Deletes an event subscription.
- info:
    name: Update Service
    type: folder
  items:
  - info:
      name: Get Update Service
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/UpdateService
    docs: Returns the firmware update service resource.
  - info:
      name: List Firmware Inventory
      type: http
    http:
      method: GET
      url: https://{bmc-ip}/redfish/v1/UpdateService/FirmwareInventory
    docs: Returns the current firmware inventory for all managed components.
  - info:
      name: Perform Simple Firmware Update
      type: http
    http:
      method: POST
      url: https://{bmc-ip}/redfish/v1/UpdateService/Actions/UpdateService.SimpleUpdate
      body:
        type: json
        data: '{}'
    docs: Initiates a firmware update for a target component using a specified firmware image URI.
bundled: true
