VMware Tanzu

VMware Tanzu (now part of Broadcom) is a portfolio of products for modernizing applications and infrastructure with a common approach to building, running, and managing Kubernetes across multi-cloud environments. Key APIs include the Tanzu Service Mesh REST API for cluster and global namespace management, Kubernetes CRD-based APIs for VM Operator, Projects Operator, and NSX Operator, and the Tanzu CLI plugin runtime.

2 APIs 0 Features

Cloud NativeContainersEnterpriseKubernetesMulti-CloudService MeshVMware

APIs

VMware Tanzu Service Mesh API

The Tanzu Service Mesh REST API provides programmatic access to manage clusters, global namespaces, resource groups, and service mesh policies. Authentication uses a CSP API tok...

VMware Tanzu Kubernetes Grid API

Kubernetes-native API for provisioning and managing Tanzu Kubernetes clusters using the TanzuKubernetesCluster CRD (v1alpha1/v1alpha2). Runs on vSphere Supervisor clusters via t...

Collections

VMware Tanzu Service Mesh API

OPEN

Pricing Plans

Vmware Tanzu Plans Pricing

3 plans

PLANS

Rate Limits

Vmware Tanzu Rate Limits

5 limits

RATE LIMITS

FinOps

Vmware Tanzu Finops

FINOPS

Semantic Vocabularies

Vmware Tanzu Context

8 classes · 25 properties

JSON-LD

API Governance Rules

VMware Tanzu API Rules

8 rules · 2 errors 6 warnings

SPECTRAL

JSON Structure

Vmware Tanzu Cluster Structure

0 properties

JSON STRUCTURE

Example Payloads

Vmware Tanzu Kubernetes Grid Create Cluster Example

5 fields

EXAMPLE

Vmware Tanzu Service Mesh List Clusters Example

5 fields

EXAMPLE

Kubernetes CRDs

tanzukubernetescluster crd

Resources

Documentation

GitHubOrganization

GitHubOrganization

Broadcom TechDocs

Broadcom TechDocs

Cartographer

Sources

opencollection: 1.0.0
info:
  name: VMware Tanzu Service Mesh API
  version: v1alpha1
items:
- info:
    name: Authentication
    type: folder
  items:
  - info:
      name: Exchange API Token for Access Token
      type: http
    http:
      method: POST
      url: https://prod-2.nsxservicemesh.vmware.com/csp/gateway/am/api/auth/api-tokens/authorize
      body:
        type: form-urlencoded
        data:
        - name: refresh_token
          value: ''
    docs: Exchange a long-lived CSP API token for a short-lived Bearer access token. The returned token must be used in the
      csp-auth-token header for all subsequent API calls.
- info:
    name: Clusters
    type: folder
  items:
  - info:
      name: List Clusters
      type: http
    http:
      method: GET
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/clusters
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Retrieve all Kubernetes clusters onboarded to Tanzu Service Mesh.
  - info:
      name: Get Cluster
      type: http
    http:
      method: GET
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/clusters/:cluster_name
      params:
      - name: cluster_name
        value: ''
        type: path
        description: The cluster name as registered in Tanzu Service Mesh
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Retrieve details for a specific onboarded cluster.
  - info:
      name: Onboard Cluster
      type: http
    http:
      method: PUT
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/clusters/:cluster_name
      params:
      - name: cluster_name
        value: ''
        type: path
        description: Unique name for the cluster in Tanzu Service Mesh
      body:
        type: json
        data: '{}'
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Onboard a Kubernetes cluster to Tanzu Service Mesh. This initiates the installation of the TSM agent on the cluster.
  - info:
      name: Remove Cluster
      type: http
    http:
      method: DELETE
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/clusters/:cluster_name
      params:
      - name: cluster_name
        value: ''
        type: path
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Remove a cluster from Tanzu Service Mesh management.
- info:
    name: Global Namespaces
    type: folder
  items:
  - info:
      name: List Global Namespaces
      type: http
    http:
      method: GET
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/global-namespaces
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: List all global namespaces. A global namespace connects workloads across multiple clusters and clouds into one virtual
      unit for consistent traffic routing, connectivity, and security.
  - info:
      name: Create Global Namespace
      type: http
    http:
      method: POST
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/global-namespaces
      body:
        type: json
        data: '{}'
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Create a new global namespace spanning multiple clusters.
  - info:
      name: Get Global Namespace
      type: http
    http:
      method: GET
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/global-namespaces/:namespace_id
      params:
      - name: namespace_id
        value: ''
        type: path
        description: Global namespace identifier
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Retrieve details for a specific global namespace.
  - info:
      name: Update Global Namespace
      type: http
    http:
      method: PUT
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/global-namespaces/:namespace_id
      params:
      - name: namespace_id
        value: ''
        type: path
      body:
        type: json
        data: '{}'
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Update the configuration of a global namespace.
  - info:
      name: Delete Global Namespace
      type: http
    http:
      method: DELETE
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/global-namespaces/:namespace_id
      params:
      - name: namespace_id
        value: ''
        type: path
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Delete a global namespace.
- info:
    name: Resource Groups
    type: folder
  items:
  - info:
      name: List Resource Groups
      type: http
    http:
      method: GET
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/resource-groups
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: List all resource groups. A resource group is a collection of cluster resources sharing specific characteristics,
      used to enforce policies and monitor performance.
  - info:
      name: Create Resource Group
      type: http
    http:
      method: POST
      url: https://prod-2.nsxservicemesh.vmware.com/v1alpha1/resource-groups
      body:
        type: json
        data: '{}'
      auth:
        type: apikey
        key: csp-auth-token
        value: '{{csp-auth-token}}'
        placement: header
    docs: Create a new resource group.
bundled: true
