tidb

opencollection: 1.0.0
info:
  name: TiDB HTTP API
  version: '1.0'
items:
- info:
    name: Status
    type: folder
  items:
  - info:
      name: Get server status
      type: http
    http:
      method: GET
      url: http://localhost:10080/status
    docs: Returns the current operational status of the TiDB server instance, including the number of active connections,
      the TiDB version string, and the git commit hash of the binary. This endpoint is commonly used by load balancers and
      health check systems to verify that the TiDB process is running and accepting connections.
  - info:
      name: Get Prometheus metrics
      type: http
    http:
      method: GET
      url: http://localhost:10080/metrics
    docs: Returns all Prometheus-format performance metrics for the TiDB server instance. This endpoint is consumed by Prometheus
      scrape jobs to collect TiDB-specific metrics including query latency, error rates, connection pool utilization, and
      internal component performance counters.
  - info:
      name: Get server information
      type: http
    http:
      method: GET
      url: http://localhost:10080/info
    docs: Returns detailed information about the TiDB server instance including version, IP address, listening port, status
      port, and the git hash of the binary. This endpoint is useful for service discovery and identifying specific nodes in
      a TiDB cluster.
  - info:
      name: Get all cluster server information
      type: http
    http:
      method: GET
      url: http://localhost:10080/info/all
    docs: Returns information about all TiDB server instances in the cluster as registered with the Placement Driver (PD).
      This provides a cluster-wide view of all running TiDB nodes and their connection endpoints.
- info:
    name: Schema
    type: folder
  items:
  - info:
      name: Get all database schemas
      type: http
    http:
      method: GET
      url: http://localhost:10080/schema
    docs: Returns schema information for all databases known to this TiDB instance. The response includes table names, column
      definitions, and index information as represented in the TiDB information schema.
  - info:
      name: Get database schema
      type: http
    http:
      method: GET
      url: http://localhost:10080/schema/:db
      params:
      - name: db
        value: ''
        type: path
        description: The database name.
      - name: id_name_only
        value: ''
        type: query
        description: If true, returns only table IDs and names without full schema details.
    docs: Returns schema information for all tables in the specified database. Optionally set id_name_only to true to return
      only table IDs and names without the full column and index details, which is faster for large schemas.
  - info:
      name: Get table schema
      type: http
    http:
      method: GET
      url: http://localhost:10080/schema/:db/:table
      params:
      - name: db
        value: ''
        type: path
        description: The database name.
      - name: table
        value: ''
        type: path
        description: The table name within the specified database.
      - name: table_id
        value: ''
        type: query
        description: Optional numeric table ID for lookup by ID instead of name.
    docs: Returns the full schema definition for the specified table, including all column names, types, default values, and
      index definitions. Can also look up a table by numeric table_id or multiple table_ids for batch retrieval.
  - info:
      name: Get table info by table ID
      type: http
    http:
      method: GET
      url: http://localhost:10080/db-table/:tableID
      params:
      - name: tableID
        value: ''
        type: path
        description: The numeric TiDB internal table ID.
    docs: Returns database information, table information, and the current TiDB info schema version for a specific table identified
      by its numeric table ID. This is useful for reverse lookups when you have a table ID from region information but need
      the associated database and table names.
- info:
    name: Regions
    type: folder
  items:
  - info:
      name: List all regions metadata
      type: http
    http:
      method: GET
      url: http://localhost:10080/regions/meta
    docs: Returns the metadata for all TiKV regions known to this TiDB instance. Each region entry includes region ID, start
      and end keys, epoch information, and peer assignments. This endpoint is primarily used for cluster topology inspection
      and debugging region distribution issues.
  - info:
      name: Get hot regions
      type: http
    http:
      method: GET
      url: http://localhost:10080/regions/hot
    docs: Returns the top hot read and write regions for each TiKV store, along with the associated table and index names.
      This endpoint is used for identifying hotspot issues in data access patterns, which can cause uneven load distribution
      across TiKV nodes.
  - info:
      name: Get a region
      type: http
    http:
      method: GET
      url: http://localhost:10080/regions/:regionID
      params:
      - name: regionID
        value: ''
        type: path
        description: The numeric TiKV region ID.
    docs: Returns detailed information about a specific TiKV region identified by its numeric region ID. Includes peer locations,
      epoch, and the associated frame information mapping the region to TiDB tables and indexes.
  - info:
      name: Get table regions
      type: http
    http:
      method: GET
      url: http://localhost:10080/tables/:db/:table/regions
      params:
      - name: db
        value: ''
        type: path
        description: The database name.
      - name: table
        value: ''
        type: path
        description: The table name within the specified database.
    docs: Returns the list of TiKV regions that store data for a specific TiDB table. Each region entry includes the region
      ID, start key, end key, leader peer, and follower peers. Use this endpoint to understand the physical data layout of
      a table across TiKV stores.
  - info:
      name: Scatter table regions
      type: http
    http:
      method: POST
      url: http://localhost:10080/tables/:db/:table/scatter
      params:
      - name: db
        value: ''
        type: path
        description: The database name.
      - name: table
        value: ''
        type: path
        description: The table name within the specified database.
    docs: Initiates region scatter for the specified table, redistributing its TiKV regions across stores to improve data
      balance. This is typically used after bulk data loads that may have caused uneven region distribution.
- info:
    name: MVCC
    type: folder
  items:
  - info:
      name: Get MVCC info by row handle
      type: http
    http:
      method: GET
      url: http://localhost:10080/mvcc/key/:db/:table/:handle
      params:
      - name: db
        value: ''
        type: path
        description: The database name.
      - name: table
        value: ''
        type: path
        description: The table name within the specified database.
      - name: handle
        value: ''
        type: path
        description: The row handle (primary key value or internal row ID) for the target row.
    docs: Returns multi-version concurrency control (MVCC) information for the key corresponding to the specified row handle
      in a table. Shows all versions of the key across transactions, including start timestamp, commit timestamp, and value.
      Used for debugging transaction conflicts and stale data issues.
  - info:
      name: Get MVCC info by hex key
      type: http
    http:
      method: GET
      url: http://localhost:10080/mvcc/hex/:hexKey
      params:
      - name: hexKey
        value: ''
        type: path
        description: The raw key encoded as a hexadecimal string.
    docs: Returns MVCC information for a key specified as a hexadecimal string. This endpoint is used when you have the raw
      encoded key from TiKV region information and need to look up the MVCC history for that specific key.
- info:
    name: DDL
    type: folder
  items:
  - info:
      name: Get DDL job history
      type: http
    http:
      method: GET
      url: http://localhost:10080/ddl/history
      params:
      - name: start_job_id
        value: ''
        type: query
        description: The DDL job ID to start listing from, for pagination.
      - name: limit
        value: ''
        type: query
        description: Maximum number of DDL job history records to return.
    docs: Returns the history of DDL (Data Definition Language) jobs executed on the cluster, such as CREATE TABLE, ALTER
      TABLE, DROP INDEX, and similar schema change operations. Results are paginated using start_job_id and limit parameters.
      DDL history is useful for auditing schema changes and diagnosing failed schema modifications.
  - info:
      name: Resign DDL owner
      type: http
    http:
      method: POST
      url: http://localhost:10080/ddl/owner/resign
    docs: Forces the current TiDB server to resign its role as the DDL owner, triggering a new DDL owner election among all
      TiDB servers in the cluster. Only one TiDB server is the DDL owner at any time and is responsible for executing schema
      change jobs. Use this endpoint when the current DDL owner is experiencing issues.
- info:
    name: Settings
    type: folder
  items:
  - info:
      name: Get server settings
      type: http
    http:
      method: GET
      url: http://localhost:10080/settings
    docs: Returns the current runtime settings of the TiDB server instance, including log level, general log status, and DDL
      slow threshold. These settings can be modified without restarting the server via the POST method of this endpoint.
  - info:
      name: Update server settings
      type: http
    http:
      method: POST
      url: http://localhost:10080/settings
      body:
        type: form-urlencoded
        data: []
    docs: Modifies one or more runtime settings of the TiDB server without requiring a restart. Supports updating general_log
      to enable or disable the general query log, log_level to change the server log verbosity, and ddl_slow_threshold to
      adjust the DDL slow operation threshold in milliseconds.
- info:
    name: Statistics
    type: folder
  items:
  - info:
      name: Dump table statistics
      type: http
    http:
      method: GET
      url: http://localhost:10080/stats/dump/:db/:table
      params:
      - name: db
        value: ''
        type: path
        description: The database name.
      - name: table
        value: ''
        type: path
        description: The table name within the specified database.
      - name: timestamp
        value: ''
        type: query
        description: Optional Unix timestamp to retrieve historical statistics at a specific point in time.
    docs: Returns the optimizer statistics for the specified table in JSON format. Statistics include histogram data, count-min
      sketch approximations, and correlation coefficients used by the TiDB query optimizer when generating execution plans.
      Optionally specify a timestamp to retrieve historical statistics.
- info:
    name: Diagnostics
    type: folder
  items:
  - info:
      name: Download debug info zip
      type: http
    http:
      method: GET
      url: http://localhost:10080/debug/zip
      params:
      - name: seconds
        value: ''
        type: query
        description: Number of seconds to collect CPU profile and goroutine data before packaging.
    docs: Returns a zip archive containing TiDB debug information useful for diagnosing production issues. The archive includes
      heap profile, CPU profile, goroutine dump, and configuration information collected over the specified number of seconds.
      This endpoint is used when filing bug reports or investigating performance problems with PingCAP support.
bundled: true
