Longhorn

opencollection: 1.0.0
info:
  name: Longhorn Manager API
  version: '1.11'
request:
  auth:
    type: bearer
    token: '{{bearerToken}}'
items:
- info:
    name: Volumes
    type: folder
  items:
  - info:
      name: Longhorn List volumes
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes
    docs: Returns a list of all Longhorn volumes in the cluster. Each volume entry includes its name, size, replication configuration,
      state, access mode, attached node, snapshot count, and associated recurring jobs.
  - info:
      name: Longhorn Create a volume
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes
      body:
        type: json
        data: '{}'
    docs: Creates a new Longhorn volume with the specified configuration. The volume will be created in a detached state.
      It must be attached to a node before data can be written. Longhorn creates the specified number of replicas distributed
      across available nodes.
  - info:
      name: Longhorn Get a volume
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
    docs: Returns detailed information about a specific volume including its state, replicas, engine, size, access mode, recurring
      jobs, and current operation status.
  - info:
      name: Longhorn Delete a volume
      type: http
    http:
      method: DELETE
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
    docs: Deletes a Longhorn volume and all of its replicas. The volume must be in a detached state before it can be deleted.
      All snapshots and backups associated with the volume will also be deleted.
  - info:
      name: Longhorn Attach a volume to a node
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName?action=attach
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
      body:
        type: json
        data: '{}'
    docs: Attaches a Longhorn volume to the specified node, making it available as a block device. The volume must be detached
      before it can be attached to a different node.
  - info:
      name: Longhorn Detach a volume from its node
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName?action=detach
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
      body:
        type: json
        data: '{}'
    docs: Detaches a Longhorn volume from the node it is currently attached to. The volume's data is preserved and it can
      be reattached to the same or a different node afterward.
  - info:
      name: Longhorn Expand a volume
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName?action=expand
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
      body:
        type: json
        data: '{}'
    docs: Expands a Longhorn volume to a new, larger size. The size must be greater than the current volume size. Online expansion
      is supported for volumes attached to nodes; the file system may need to be resized separately after the volume is expanded.
- info:
    name: Snapshots
    type: folder
  items:
  - info:
      name: Longhorn Create a snapshot
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName?action=snapshotCreate
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
      body:
        type: json
        data: '{}'
    docs: Creates a point-in-time snapshot of a Longhorn volume. The volume must be attached when the snapshot is created.
      Snapshots are stored in the volume's replica data directories and consume incremental space for changed blocks.
  - info:
      name: Longhorn List snapshots for a volume
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName?action=snapshotList
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
    docs: Returns a list of all snapshots for the specified volume. Each entry includes the snapshot name, creation time,
      size, parent, labels, and whether it has been removed or backed up.
  - info:
      name: Longhorn Delete a snapshot
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName?action=snapshotDelete
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
      body:
        type: json
        data: '{}'
    docs: Marks a snapshot for deletion. The snapshot data is reclaimed asynchronously. Deleting a snapshot merges its changed
      blocks with the next snapshot in the chain. The volume must be attached.
  - info:
      name: Longhorn Revert a volume to a snapshot
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName?action=snapshotRevert
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
      body:
        type: json
        data: '{}'
    docs: Reverts the contents of a volume to the state captured in a specific snapshot. The volume must be detached before
      a revert operation. All data written after the snapshot was created will be lost.
- info:
    name: Backups
    type: folder
  items:
  - info:
      name: Longhorn Back up a snapshot
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/volumes/:volumeName?action=snapshotBackup
      params:
      - name: volumeName
        value: ''
        type: path
        description: Name of the Longhorn volume.
      body:
        type: json
        data: '{}'
    docs: Triggers a backup of a specific snapshot to the configured external backup target (S3 or NFS). The backup is asynchronous;
      monitor the backup resource to track progress.
  - info:
      name: Longhorn List backup volumes
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/backupvolumes
    docs: Returns a list of all backup volumes in the configured backup target. A backup volume contains one or more backups
      of a Longhorn volume. This endpoint queries the external backup store.
  - info:
      name: Longhorn Get a backup volume
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/backupvolumes/:backupVolumeName
      params:
      - name: backupVolumeName
        value: ''
        type: path
        description: Name of the backup volume in the backup store.
    docs: Returns details of a specific backup volume from the backup store including the list of available backups and their
      metadata.
  - info:
      name: Longhorn List backups for a backup volume
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/backupvolumes/:backupVolumeName/backups
      params:
      - name: backupVolumeName
        value: ''
        type: path
        description: Name of the backup volume in the backup store.
    docs: Returns a list of all backups stored for a specific backup volume. Each backup corresponds to a snapshot of the
      source Longhorn volume at the time the backup was created.
- info:
    name: Nodes
    type: folder
  items:
  - info:
      name: Longhorn List nodes
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/nodes
    docs: Returns a list of all nodes in the Longhorn storage cluster. Each node entry includes its scheduling eligibility,
      disk configurations, conditions, tags, and current state.
  - info:
      name: Longhorn Get a node
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/nodes/:nodeId
      params:
      - name: nodeId
        value: ''
        type: path
        description: Identifier of the Longhorn node (typically the Kubernetes node name).
    docs: Returns detailed information about a specific node including all configured disks, their storage capacity, scheduling
      status, tags, and health conditions.
  - info:
      name: Longhorn Update a node
      type: http
    http:
      method: PUT
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/nodes/:nodeId
      params:
      - name: nodeId
        value: ''
        type: path
        description: Identifier of the Longhorn node (typically the Kubernetes node name).
      body:
        type: json
        data: '{}'
    docs: Updates a node's configuration including scheduling eligibility, disk configurations, eviction status, and node
      tags for workload placement affinity.
- info:
    name: EngineImages
    type: folder
  items:
  - info:
      name: Longhorn List engine images
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/engineimages
    docs: Returns a list of all Longhorn engine images installed in the cluster. Engine images contain the Longhorn storage
      engine binary and are used to manage volume upgrade and compatibility.
  - info:
      name: Longhorn Create an engine image
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/engineimages
      body:
        type: json
        data: '{}'
    docs: Deploys a new Longhorn engine image to the cluster by specifying an OCI image reference. Longhorn deploys the engine
      binary from this image to all nodes via a DaemonSet.
  - info:
      name: Longhorn Get an engine image
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/engineimages/:engineImageName
      params:
      - name: engineImageName
        value: ''
        type: path
        description: Name of the engine image resource.
    docs: Returns details of a specific engine image including its deployment state, CLI API version, controller API version,
      and which nodes have the image deployed.
  - info:
      name: Longhorn Delete an engine image
      type: http
    http:
      method: DELETE
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/engineimages/:engineImageName
      params:
      - name: engineImageName
        value: ''
        type: path
        description: Name of the engine image resource.
    docs: Removes an engine image from the cluster. The default engine image and images currently in use by volumes cannot
      be deleted.
- info:
    name: RecurringJobs
    type: folder
  items:
  - info:
      name: Longhorn List recurring jobs
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/recurringjobs
    docs: Returns a list of all recurring snapshot and backup jobs configured in Longhorn. Recurring jobs can be assigned
      to individual volumes or to groups that apply to multiple volumes.
  - info:
      name: Longhorn Create a recurring job
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/recurringjobs
      body:
        type: json
        data: '{}'
    docs: Creates a new recurring job for automated snapshot or backup operations. The job runs on the specified cron schedule
      and applies to all volumes that have this job in their recurring job list or that belong to the job's group.
  - info:
      name: Longhorn Get a recurring job
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/recurringjobs/:recurringJobName
      params:
      - name: recurringJobName
        value: ''
        type: path
        description: Name of the recurring job.
    docs: Returns details of a specific recurring job including its schedule, task type, retention policy, labels, and group
      assignments.
  - info:
      name: Longhorn Update a recurring job
      type: http
    http:
      method: PUT
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/recurringjobs/:recurringJobName
      params:
      - name: recurringJobName
        value: ''
        type: path
        description: Name of the recurring job.
      body:
        type: json
        data: '{}'
    docs: Updates a recurring job's configuration including schedule, retention count, concurrency, and group assignments.
  - info:
      name: Longhorn Delete a recurring job
      type: http
    http:
      method: DELETE
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/recurringjobs/:recurringJobName
      params:
      - name: recurringJobName
        value: ''
        type: path
        description: Name of the recurring job.
    docs: Deletes a recurring job. Volumes assigned to this job will no longer have automated snapshots or backups created
      by this schedule.
- info:
    name: Settings
    type: folder
  items:
  - info:
      name: Longhorn List all settings
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/settings
    docs: Returns a list of all Longhorn system settings including backup target, default replica count, data locality, storage
      over-provisioning percentage, and all other configurable system parameters.
  - info:
      name: Longhorn Get a setting
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/settings/:settingName
      params:
      - name: settingName
        value: ''
        type: path
        description: Key name of the Longhorn setting.
    docs: Returns the current value and metadata for a specific Longhorn setting. Settings include backup targets, replica
      counts, CPU and memory limits, node scheduling policies, and many other system parameters.
  - info:
      name: Longhorn Update a setting
      type: http
    http:
      method: PUT
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/settings/:settingName
      params:
      - name: settingName
        value: ''
        type: path
        description: Key name of the Longhorn setting.
      body:
        type: json
        data: '{}'
    docs: Updates the value of a specific Longhorn system setting. Changes take effect immediately without requiring a restart.
- info:
    name: BackingImages
    type: folder
  items:
  - info:
      name: Longhorn List backing images
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/backingimages
    docs: Returns a list of all backing images available in the cluster. Backing images are pre-populated disk images used
      as the base for new volumes.
  - info:
      name: Longhorn Create a backing image
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/backingimages
      body:
        type: json
        data: '{}'
    docs: Creates a new backing image by uploading or downloading an image file. The backing image is distributed to all nodes
      that need it for volume creation.
- info:
    name: SystemBackups
    type: folder
  items:
  - info:
      name: Longhorn List system backups
      type: http
    http:
      method: GET
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/systembackups
    docs: Returns a list of all system-level backups. System backups capture the entire Longhorn configuration including all
      CRDs, settings, and metadata to enable full cluster restoration.
  - info:
      name: Longhorn Create a system backup
      type: http
    http:
      method: POST
      url: http://{longhornManagerHost}:{longhornManagerPort}/v1/systembackups
      body:
        type: json
        data: '{}'
    docs: Creates a new system-level backup of the Longhorn configuration. The backup is stored in the configured backup target
      and can be used to restore the entire Longhorn installation.
bundled: true
