OSIsoft PI System is a real-time data management platform used by industrial organizations to capture, analyze, and visualize operational data from sensors, devices, and applications.

3 APIs 0 Features

APIs

OSIsoft PI Web API

OSIsoft PI Web API (now part of AVEVA) provides a REST interface for accessing the PI System process historian. APIs enable real-time and historical time-series data retrieval, ...

AVEVA CONNECT Data Services API

AVEVA CONNECT (formerly AVEVA Data Hub / OSIsoft Cloud Services) provides cloud-native REST APIs for industrial time-series data management, data views, event data, and secure c...

OSIsoft PI AF SDK

OSIsoft PI Asset Framework SDK (AF SDK) is a .NET client library for programmatic access to the PI System asset hierarchy, time-series data, and event frames from on-premises PI...

Collections

OSIsoft PI Web API

OPEN

Pricing Plans

Osisoft Pi Plans Pricing

1 plans

PLANS

Rate Limits

Osisoft Pi Rate Limits

2 limits

RATE LIMITS

FinOps

Osisoft Pi Finops

FINOPS

Semantic Vocabularies

Osisoft Pi Context

0 classes · 23 properties

JSON-LD

Resources

🔗
TrustCenter
TrustCenter
🔗
VulnerabilityDisclosure
VulnerabilityDisclosure
🔗
DomainSecurity
DomainSecurity
🔑
Authentication
Authentication
🔗
LinkedIn
LinkedIn
🌐
Portal
Portal
🔗
Documentation
Documentation
🚀
GettingStarted
GettingStarted
🔗
Website
Website
💬
Support
Support
💬
Support
Support
🔗
Documentation
Documentation
👥
GitHubOrganization
GitHubOrganization
📦
SDKs
SDKs
🔗
OpenAPI
OpenAPI
🔗
JSONSchema
JSONSchema
🔗
JSONSchema
JSONSchema
🔗
JSONLDContext
JSONLDContext

Sources

Raw ↑
opencollection: 1.0.0
info:
  name: OSIsoft PI Web API
  version: 2023.2.0
request:
  auth:
    type: basic
    username: '{{username}}'
    password: '{{password}}'
items:
- info:
    name: DataServers
    type: folder
  items:
  - info:
      name: List PI Data Archive servers
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/dataservers
      params:
      - name: selectedFields
        value: ''
        type: query
        description: Comma-separated list of fields to return
    docs: Returns all registered PI Data Archive servers accessible via this PI Web API instance.
- info:
    name: PIPoints
    type: folder
  items:
  - info:
      name: List PI points on a server
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/dataservers/:webId/points
      params:
      - name: webId
        value: ''
        type: path
        description: PI Web API WebId (unique opaque identifier for PI System objects)
      - name: nameFilter
        value: ''
        type: query
        description: Wildcard filter for tag names (e.g. *.FLOW)
      - name: type
        value: ''
        type: query
        description: Filter by point type
      - name: maxCount
        value: ''
        type: query
      - name: startIndex
        value: ''
        type: query
      - name: selectedFields
        value: ''
        type: query
    docs: Returns PI points (tags) on the specified PI Data Archive server with optional name filtering.
  - info:
      name: Get a PI point
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/points/:webId
      params:
      - name: webId
        value: ''
        type: path
        description: PI Web API WebId (unique opaque identifier for PI System objects)
      - name: selectedFields
        value: ''
        type: query
    docs: Returns PI point configuration and metadata.
- info:
    name: Streams
    type: folder
  items:
  - info:
      name: Get current stream value
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/streams/:webId/value
      params:
      - name: webId
        value: ''
        type: path
        description: PI Web API WebId (unique opaque identifier for PI System objects)
      - name: desiredUnits
        value: ''
        type: query
        description: Unit of measure for the returned value
      - name: selectedFields
        value: ''
        type: query
    docs: Returns the current (snapshot) value for a PI point or AF attribute stream.
  - info:
      name: Get recorded stream values
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/streams/:webId/recorded
      params:
      - name: webId
        value: ''
        type: path
        description: PI Web API WebId (unique opaque identifier for PI System objects)
      - name: startTime
        value: ''
        type: query
        description: Start time (absolute or relative, e.g. "*-1d" or "2026-03-01T00:00:00Z")
      - name: endTime
        value: ''
        type: query
        description: End time
      - name: boundaryType
        value: ''
        type: query
      - name: maxCount
        value: ''
        type: query
      - name: desiredUnits
        value: ''
        type: query
      - name: selectedFields
        value: ''
        type: query
    docs: Returns archive (recorded) values for a PI point or AF attribute within a time range.
  - info:
      name: Get interpolated stream values
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/streams/:webId/interpolated
      params:
      - name: webId
        value: ''
        type: path
        description: PI Web API WebId (unique opaque identifier for PI System objects)
      - name: startTime
        value: ''
        type: query
      - name: endTime
        value: ''
        type: query
      - name: interval
        value: ''
        type: query
        description: Interval between values (e.g. "1h", "5m")
      - name: desiredUnits
        value: ''
        type: query
      - name: maxCount
        value: ''
        type: query
      - name: selectedFields
        value: ''
        type: query
    docs: Returns interpolated values at a fixed time interval within a time range.
  - info:
      name: Get stream summary statistics
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/streams/:webId/summary
      params:
      - name: webId
        value: ''
        type: path
        description: PI Web API WebId (unique opaque identifier for PI System objects)
      - name: startTime
        value: ''
        type: query
      - name: endTime
        value: ''
        type: query
      - name: summaryType
        value: ''
        type: query
        description: Comma-separated summary types
      - name: calculationBasis
        value: ''
        type: query
    docs: Returns statistical summaries (min, max, average, count, etc.) for a stream over a time range.
- info:
    name: AssetServers
    type: folder
  items:
  - info:
      name: List Asset Framework servers
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/assetservers
    docs: Returns all registered PI Asset Framework (AF) servers.
- info:
    name: Elements
    type: folder
  items:
  - info:
      name: List AF elements
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/assetdatabases/:webId/elements
      params:
      - name: webId
        value: ''
        type: path
        description: PI Web API WebId (unique opaque identifier for PI System objects)
      - name: nameFilter
        value: ''
        type: query
      - name: templateName
        value: ''
        type: query
      - name: maxCount
        value: ''
        type: query
      - name: selectedFields
        value: ''
        type: query
    docs: Returns top-level AF elements in an asset database.
- info:
    name: Attributes
    type: folder
  items:
  - info:
      name: List element attributes
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/elements/:webId/attributes
      params:
      - name: webId
        value: ''
        type: path
        description: PI Web API WebId (unique opaque identifier for PI System objects)
      - name: nameFilter
        value: ''
        type: query
      - name: selectedFields
        value: ''
        type: query
    docs: Returns attributes of an AF element.
- info:
    name: EventFrames
    type: folder
  items:
  - info:
      name: Query event frames
      type: http
    http:
      method: GET
      url: https://{piwebapi_host}/piwebapi/eventframes
      params:
      - name: databaseWebId
        value: ''
        type: query
        description: AF database WebId to search
      - name: startTime
        value: ''
        type: query
      - name: endTime
        value: ''
        type: query
      - name: nameFilter
        value: ''
        type: query
      - name: templateName
        value: ''
        type: query
      - name: maxCount
        value: ''
        type: query
      - name: selectedFields
        value: ''
        type: query
    docs: Returns event frames matching specified criteria within a time range.
- info:
    name: BatchRequests
    type: folder
  items:
  - info:
      name: Execute a batch request
      type: http
    http:
      method: POST
      url: https://{piwebapi_host}/piwebapi/batch
      body:
        type: json
        data: '{}'
    docs: Executes multiple PI Web API requests in a single HTTP call. Supports sequential and parallel execution with parameter
      substitution between requests.
bundled: true
