Jaeger

Jaeger is an open source, end-to-end distributed tracing system for monitoring and troubleshooting microservices-based architectures. Jaeger provides visibility into distributed system behavior through trace collection, storage, and visualization.

4 APIs 0 Features

Distributed TracingMicroservicesMonitoringObservability

APIs

Jaeger Query API

The Jaeger Query API is an HTTP/JSON API exposed by the Jaeger Query service for retrieving distributed traces, listing services and operations, querying service dependency grap...

Jaeger Collector API

The Jaeger Collector API receives trace spans from instrumented applications and SDKs. Since Jaeger v1.11 the primary protocol is the jaeger.api_v2.CollectorService gRPC endpoin...

Jaeger Remote Storage API

The Jaeger Remote Storage API is a gRPC-based interface that allows extending Jaeger with custom storage backends. Any backend implementing this API can be deployed as a remote ...

Jaeger Remote Sampling API

The Jaeger Remote Sampling API provides HTTP and gRPC endpoints that SDKs use to retrieve sampling strategies for distributed trace collection. It is implemented by the jaeger-c...

Collections

Jaeger Query API

OPEN

Pricing Plans

Jaeger Plans Pricing

3 plans

PLANS

Rate Limits

Jaeger Rate Limits

5 limits

RATE LIMITS

FinOps

Jaeger Finops

FINOPS

Resources

GitHubOrganization

Sources

opencollection: 1.0.0
info:
  name: Jaeger Query API
  version: 1.0.0
items:
- info:
    name: Traces
    type: folder
  items:
  - info:
      name: Search traces
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/traces
      params:
      - name: service
        value: ''
        type: query
        description: The service name to filter traces by.
      - name: operation
        value: ''
        type: query
        description: The operation name to filter traces by.
      - name: tags
        value: ''
        type: query
        description: Tags to filter by in JSON format, e.g. {"http.status_code":"200"}.
      - name: start
        value: ''
        type: query
        description: Start time as Unix microseconds.
      - name: end
        value: ''
        type: query
        description: End time as Unix microseconds.
      - name: minDuration
        value: ''
        type: query
        description: Minimum trace duration filter, specified as a duration string (e.g. 1.2s, 100ms, 500us).
      - name: maxDuration
        value: ''
        type: query
        description: Maximum trace duration filter, specified as a duration string (e.g. 1.2s, 100ms, 500us).
      - name: limit
        value: ''
        type: query
        description: Maximum number of traces to return.
      - name: lookback
        value: ''
        type: query
        description: How far back to search for traces, specified as a duration string (e.g. 1h, 2d). Only used if start and
          end are not set.
    docs: Search for traces matching the specified query parameters. Returns a list of traces filtered by service, operation,
      tags, duration, and time range.
  - info:
      name: Get a trace by ID
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/traces/:traceID
      params:
      - name: traceID
        value: ''
        type: path
        description: The trace ID in hexadecimal format (16 or 32 hex characters).
      - name: raw
        value: ''
        type: query
        description: Return raw trace data without post-processing.
      - name: prettyPrint
        value: ''
        type: query
        description: Pretty-print the JSON response.
    docs: Retrieve a single trace by its unique trace identifier.
- info:
    name: Services
    type: folder
  items:
  - info:
      name: Get all services
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/services
    docs: Retrieve a list of all service names that have reported spans to the Jaeger backend.
  - info:
      name: Get operations for a service
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/services/:service/operations
      params:
      - name: service
        value: ''
        type: path
        description: The service name.
      - name: spanKind
        value: ''
        type: query
        description: Filter operations by span kind (e.g. server, client, producer, consumer).
    docs: Retrieve a list of operation names for a given service. Operations represent the individual endpoints or functions
      being traced within a service.
- info:
    name: Dependencies
    type: folder
  items:
  - info:
      name: Get service dependency graph
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/dependencies
      params:
      - name: endTs
        value: ''
        type: query
        description: End timestamp in Unix milliseconds.
      - name: lookback
        value: ''
        type: query
        description: Duration to look back from endTs in milliseconds.
    docs: Retrieve the dependency graph showing relationships between services based on observed traces. Returns edges representing
      calls from one service to another with call counts.
- info:
    name: Metrics
    type: folder
  items:
  - info:
      name: Get latency metrics
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/metrics/latencies
      params:
      - name: service
        value: ''
        type: query
        description: The service name.
      - name: quantile
        value: ''
        type: query
        description: The quantile to retrieve (e.g. 0.5, 0.75, 0.95, 0.99).
      - name: endTs
        value: ''
        type: query
        description: End timestamp in Unix milliseconds.
      - name: lookback
        value: ''
        type: query
        description: Duration to look back in milliseconds.
      - name: step
        value: ''
        type: query
        description: Step duration for bucketing in milliseconds.
      - name: ratePer
        value: ''
        type: query
        description: Rate normalization duration in milliseconds.
      - name: spanKind
        value: ''
        type: query
        description: Filter by span kind.
    docs: Retrieve latency metrics (P50, P75, P95, P99) for a service, grouped by time buckets. Requires the metrics storage
      backend to be configured.
  - info:
      name: Get call rate metrics
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/metrics/calls
      params:
      - name: service
        value: ''
        type: query
        description: The service name.
      - name: endTs
        value: ''
        type: query
        description: End timestamp in Unix milliseconds.
      - name: lookback
        value: ''
        type: query
        description: Duration to look back in milliseconds.
      - name: step
        value: ''
        type: query
        description: Step duration for bucketing in milliseconds.
      - name: ratePer
        value: ''
        type: query
        description: Rate normalization duration in milliseconds.
      - name: spanKind
        value: ''
        type: query
        description: Filter by span kind.
    docs: Retrieve call rate metrics for a service, grouped by time buckets. Requires the metrics storage backend to be configured.
  - info:
      name: Get error rate metrics
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/metrics/errors
      params:
      - name: service
        value: ''
        type: query
        description: The service name.
      - name: endTs
        value: ''
        type: query
        description: End timestamp in Unix milliseconds.
      - name: lookback
        value: ''
        type: query
        description: Duration to look back in milliseconds.
      - name: step
        value: ''
        type: query
        description: Step duration for bucketing in milliseconds.
      - name: ratePer
        value: ''
        type: query
        description: Rate normalization duration in milliseconds.
      - name: spanKind
        value: ''
        type: query
        description: Filter by span kind.
    docs: Retrieve error rate metrics for a service, grouped by time buckets. Requires the metrics storage backend to be configured.
  - info:
      name: Get minimum step duration
      type: http
    http:
      method: GET
      url: http://localhost:16686/api/metrics/minstep
    docs: Retrieve the minimum time resolution (step) supported by the metrics backend.
bundled: true
