Tempo

opencollection: 1.0.0
info:
  name: Grafana Tempo HTTP API
  version: 2.x
items:
- info:
    name: Traces
    type: folder
  items:
  - info:
      name: Get Trace By ID
      type: http
    http:
      method: GET
      url: http://localhost:3200/api/traces/:traceID
      params:
      - name: traceID
        value: ''
        type: path
        description: Hexadecimal trace identifier
      - name: start
        value: ''
        type: query
        description: Unix epoch start time for search window (seconds)
      - name: end
        value: ''
        type: query
        description: Unix epoch end time for search window (seconds)
    docs: Retrieve a complete trace by its trace ID. Returns all spans belonging to the trace in JSON format. Supports deep
      object storage search when the trace is not in recent cache.
- info:
    name: Search
    type: folder
  items:
  - info:
      name: Search Traces
      type: http
    http:
      method: GET
      url: http://localhost:3200/api/search
      params:
      - name: q
        value: '{.service.name="order-service"}'
        type: query
        description: TraceQL query string
      - name: tags
        value: ''
        type: query
        description: 'URL-encoded logfmt tag filter (deprecated — use q with TraceQL instead). Example: service.name=frontend'
      - name: minDuration
        value: ''
        type: query
        description: Minimum trace duration filter (e.g., 100ms, 1s, 2m)
      - name: maxDuration
        value: ''
        type: query
        description: Maximum trace duration filter (e.g., 100ms, 1s, 2m)
      - name: limit
        value: ''
        type: query
        description: Maximum number of search results to return
      - name: start
        value: ''
        type: query
        description: Unix epoch start time for search window (seconds)
      - name: end
        value: ''
        type: query
        description: Unix epoch end time for search window (seconds)
    docs: Search for traces matching a TraceQL query or tag-based filter. Returns a list of matching trace metadata with root
      span information, duration, and service names.
- info:
    name: Tags
    type: folder
  items:
  - info:
      name: List Tag Keys
      type: http
    http:
      method: GET
      url: http://localhost:3200/api/search/tags
      params:
      - name: scope
        value: ''
        type: query
        description: Attribute scope filter (span, resource, intrinsic)
      - name: start
        value: ''
        type: query
        description: Unix epoch start time
      - name: end
        value: ''
        type: query
        description: Unix epoch end time
    docs: Returns all tag keys (span attribute names) present in the trace data within the configured search window. Useful
      for building search UIs and TraceQL autocomplete.
  - info:
      name: List Tag Values
      type: http
    http:
      method: GET
      url: http://localhost:3200/api/search/tag/:tagName/values
      params:
      - name: tagName
        value: service.name
        type: path
        description: Tag key name to retrieve values for
      - name: q
        value: ''
        type: query
        description: TraceQL query context for filtering tag values
      - name: start
        value: ''
        type: query
        description: Unix epoch start time
      - name: end
        value: ''
        type: query
        description: Unix epoch end time
    docs: Returns all distinct values for a specific tag key within the trace data. Used for building search filter dropdowns
      and TraceQL query autocomplete.
- info:
    name: Metrics
    type: folder
  items:
  - info:
      name: Query Metrics Range
      type: http
    http:
      method: GET
      url: http://localhost:3200/api/metrics/query_range
      params:
      - name: q
        value: rate({.service.name="order-service"}[5m])
        type: query
        description: TraceQL metrics query expression
      - name: start
        value: ''
        type: query
        description: Start time as Unix epoch (seconds)
      - name: end
        value: ''
        type: query
        description: End time as Unix epoch (seconds)
      - name: step
        value: ''
        type: query
        description: Query step interval (e.g., 30s, 1m, 5m)
    docs: Generate time-series metrics from trace data using TraceQL metrics queries. Supports span rate, error rate, duration
      histograms, and custom metric generation from trace attributes.
- info:
    name: Health
    type: folder
  items:
  - info:
      name: Check Readiness
      type: http
    http:
      method: GET
      url: http://localhost:3200/ready
    docs: Readiness probe endpoint. Returns 200 OK when Tempo is ready to serve requests. Used by Kubernetes readiness probes
      and load balancers.
  - info:
      name: Get Prometheus Metrics
      type: http
    http:
      method: GET
      url: http://localhost:3200/metrics
    docs: Exposes Tempo's own operational Prometheus metrics including ingestion rate, query latency, cache hit rates, and
      storage backend metrics. Scraped by Prometheus or Grafana Agent for Tempo self-monitoring.
bundled: true
