SimScale

SimScale is a cloud-based computer-aided engineering (CAE) platform offering computational fluid dynamics (CFD), finite element analysis (FEA), and thermal simulation capabilities. The SimScale REST API enables programmatic project management, geometry upload, mesh generation, simulation setup and execution, and results extraction for engineering automation workflows.

1 APIs 0 Features

CAECFDFEASimulationEngineering

APIs

SimScale REST API

The SimScale REST API provides programmatic access to the SimScale cloud simulation platform. Developers can manage projects, upload CAD geometry, configure meshing operations, ...

Collections

SimScale REST API

OPEN

Pricing Plans

Simscale Plans Pricing

3 plans

PLANS

Rate Limits

Simscale Rate Limits

5 limits

RATE LIMITS

FinOps

Simscale Finops

FINOPS

Semantic Vocabularies

Simscale Context

25 classes · 4 properties

JSON-LD

API Governance Rules

SimScale API Rules

9 rules · 2 errors 6 warnings 1 info

SPECTRAL

JSON Structure

Simscale Project Structure

0 properties

JSON STRUCTURE

Example Payloads

Simscale Create Project Example

4 fields

EXAMPLE

Simscale Create Simulation Run Example

4 fields

EXAMPLE

Resources

🔗

LinkedIn

👥

GitHubOrganization

Sources

opencollection: 1.0.0
info:
  name: SimScale REST API
  version: 0.0.0
request:
  auth:
    type: apikey
    key: X-API-KEY
    value: '{{X-API-KEY}}'
    placement: header
items:
- info:
    name: Projects
    type: folder
  items:
  - info:
      name: List Projects
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects
      params:
      - name: limit
        value: ''
        type: query
        description: Number of projects to return
      - name: page
        value: ''
        type: query
        description: Page number (zero-indexed)
    docs: Retrieve a list of all simulation projects for the authenticated user.
  - info:
      name: Create Project
      type: http
    http:
      method: POST
      url: https://api.simscale.com/v0/projects
      body:
        type: json
        data: '{}'
    docs: Create a new simulation project.
  - info:
      name: Get Project
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id
      params:
      - name: project_id
        value: ''
        type: path
        description: Unique project identifier
    docs: Retrieve details of a specific simulation project.
  - info:
      name: Update Project
      type: http
    http:
      method: PUT
      url: https://api.simscale.com/v0/projects/:project_id
      params:
      - name: project_id
        value: ''
        type: path
        description: Unique project identifier
      body:
        type: json
        data: '{}'
    docs: Update the name or description of an existing project.
  - info:
      name: Delete Project
      type: http
    http:
      method: DELETE
      url: https://api.simscale.com/v0/projects/:project_id
      params:
      - name: project_id
        value: ''
        type: path
        description: Unique project identifier
    docs: Delete a simulation project and all its associated data.
- info:
    name: Storage
    type: folder
  items:
  - info:
      name: Create Storage
      type: http
    http:
      method: POST
      url: https://api.simscale.com/v0/storage
    docs: Create a storage location for uploading a CAD file. Returns a presigned upload URL.
- info:
    name: Geometry
    type: folder
  items:
  - info:
      name: List Geometries
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/geometries
      params:
      - name: project_id
        value: ''
        type: path
        description: Unique project identifier
    docs: Retrieve all CAD geometries imported into a project.
  - info:
      name: Import Geometry
      type: http
    http:
      method: POST
      url: https://api.simscale.com/v0/projects/:project_id/geometries
      params:
      - name: project_id
        value: ''
        type: path
        description: Unique project identifier
      body:
        type: json
        data: '{}'
    docs: Import a CAD geometry file (previously uploaded to storage) into a project.
  - info:
      name: Get Geometry
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/geometries/:geometry_id
      params:
      - name: project_id
        value: ''
        type: path
      - name: geometry_id
        value: ''
        type: path
        description: Unique geometry identifier
    docs: Retrieve details and status of a specific geometry import.
- info:
    name: Simulations
    type: folder
  items:
  - info:
      name: List Simulations
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/simulations
      params:
      - name: project_id
        value: ''
        type: path
    docs: Retrieve all simulations defined within a project.
  - info:
      name: Create Simulation
      type: http
    http:
      method: POST
      url: https://api.simscale.com/v0/projects/:project_id/simulations
      params:
      - name: project_id
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Create a new simulation specification within a project, specifying the physics model and geometry.
  - info:
      name: Get Simulation
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/simulations/:simulation_id
      params:
      - name: project_id
        value: ''
        type: path
      - name: simulation_id
        value: ''
        type: path
        description: Unique simulation identifier
    docs: Retrieve the full specification and status of a specific simulation.
  - info:
      name: Update Simulation
      type: http
    http:
      method: PUT
      url: https://api.simscale.com/v0/projects/:project_id/simulations/:simulation_id
      params:
      - name: project_id
        value: ''
        type: path
      - name: simulation_id
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Update the specification of an existing simulation.
- info:
    name: Mesh Operations
    type: folder
  items:
  - info:
      name: List Mesh Operations
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/mesh-operations
      params:
      - name: project_id
        value: ''
        type: path
    docs: Retrieve all mesh generation operations within a project.
  - info:
      name: Create Mesh Operation
      type: http
    http:
      method: POST
      url: https://api.simscale.com/v0/projects/:project_id/mesh-operations
      params:
      - name: project_id
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Create a new mesh generation operation for a geometry.
  - info:
      name: Get Mesh Operation
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/mesh-operations/:mesh_operation_id
      params:
      - name: project_id
        value: ''
        type: path
      - name: mesh_operation_id
        value: ''
        type: path
        description: Unique mesh operation identifier
    docs: Retrieve the status and details of a specific mesh operation.
  - info:
      name: Start Mesh Operation
      type: http
    http:
      method: POST
      url: https://api.simscale.com/v0/projects/:project_id/mesh-operations/:mesh_operation_id/start
      params:
      - name: project_id
        value: ''
        type: path
      - name: mesh_operation_id
        value: ''
        type: path
    docs: Trigger execution of a mesh generation operation.
- info:
    name: Simulation Runs
    type: folder
  items:
  - info:
      name: List Simulation Runs
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/simulations/:simulation_id/runs
      params:
      - name: project_id
        value: ''
        type: path
      - name: simulation_id
        value: ''
        type: path
    docs: Retrieve all execution runs for a specific simulation.
  - info:
      name: Create Simulation Run
      type: http
    http:
      method: POST
      url: https://api.simscale.com/v0/projects/:project_id/simulations/:simulation_id/runs
      params:
      - name: project_id
        value: ''
        type: path
      - name: simulation_id
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Create and start a new execution run for a simulation.
  - info:
      name: Get Simulation Run
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/simulations/:simulation_id/runs/:run_id
      params:
      - name: project_id
        value: ''
        type: path
      - name: simulation_id
        value: ''
        type: path
      - name: run_id
        value: ''
        type: path
        description: Unique run identifier
    docs: Retrieve the status and progress of a specific simulation run.
- info:
    name: Reports
    type: folder
  items:
  - info:
      name: Get Simulation Results
      type: http
    http:
      method: GET
      url: https://api.simscale.com/v0/projects/:project_id/simulations/:simulation_id/runs/:run_id/results
      params:
      - name: project_id
        value: ''
        type: path
      - name: simulation_id
        value: ''
        type: path
      - name: run_id
        value: ''
        type: path
    docs: Retrieve result data and download links for a completed simulation run.
bundled: true
