opencollection: 1.0.0
info:
  name: RouterOS REST API
  version: 7.1+
request:
  auth:
    type: basic
    username: '{{username}}'
    password: '{{password}}'
items:
- info:
    name: IP Address
    type: folder
  items:
  - info:
      name: List IP Addresses
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/address
      params:
      - name: .proplist
        value: address,interface,network
        type: query
        description: Comma-separated list of properties to return
      - name: interface
        value: ''
        type: query
        description: Filter by interface name
      - name: dynamic
        value: ''
        type: query
        description: Filter by dynamic flag
    docs: Retrieve all IP address configurations on the device.
  - info:
      name: Add IP Address
      type: http
    http:
      method: PUT
      url: https://{routerIP}/rest/ip/address
      body:
        type: json
        data: '{}'
    docs: Add a new IP address to an interface.
  - info:
      name: Get IP Address
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/address/:id
      params:
      - name: id
        value: '*1'
        type: path
        description: RouterOS internal record identifier
    docs: Retrieve a specific IP address by ID.
  - info:
      name: Update IP Address
      type: http
    http:
      method: PATCH
      url: https://{routerIP}/rest/ip/address/:id
      params:
      - name: id
        value: '*1'
        type: path
        description: RouterOS internal record identifier
      body:
        type: json
        data: '{}'
    docs: Modify an existing IP address configuration.
  - info:
      name: Delete IP Address
      type: http
    http:
      method: DELETE
      url: https://{routerIP}/rest/ip/address/:id
      params:
      - name: id
        value: '*1'
        type: path
        description: RouterOS internal record identifier
    docs: Remove an IP address from an interface.
- info:
    name: Interface
    type: folder
  items:
  - info:
      name: List Interfaces
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/interface
      params:
      - name: type
        value: ''
        type: query
        description: Filter by interface type (ether, bridge, vlan, etc.)
      - name: running
        value: ''
        type: query
        description: Filter by running state
    docs: Retrieve all network interfaces on the device.
  - info:
      name: Get Interface
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/interface/:id
      params:
      - name: id
        value: '*1'
        type: path
        description: RouterOS internal record identifier
    docs: Retrieve a specific interface by ID.
  - info:
      name: Update Interface
      type: http
    http:
      method: PATCH
      url: https://{routerIP}/rest/interface/:id
      params:
      - name: id
        value: '*1'
        type: path
        description: RouterOS internal record identifier
      body:
        type: json
        data: '{}'
    docs: Modify an existing interface configuration.
- info:
    name: Firewall
    type: folder
  items:
  - info:
      name: List Firewall Filter Rules
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/firewall/filter
      params:
      - name: chain
        value: ''
        type: query
        description: Filter by chain (input, forward, output)
      - name: action
        value: ''
        type: query
        description: Filter by action (accept, drop, reject)
    docs: Retrieve all firewall filter rules.
  - info:
      name: Add Firewall Filter Rule
      type: http
    http:
      method: PUT
      url: https://{routerIP}/rest/ip/firewall/filter
      body:
        type: json
        data: '{}'
    docs: Add a new firewall filter rule.
  - info:
      name: Update Firewall Filter Rule
      type: http
    http:
      method: PATCH
      url: https://{routerIP}/rest/ip/firewall/filter/:id
      params:
      - name: id
        value: '*1'
        type: path
        description: RouterOS internal record identifier
      body:
        type: json
        data: '{}'
    docs: Modify an existing firewall filter rule.
  - info:
      name: Delete Firewall Filter Rule
      type: http
    http:
      method: DELETE
      url: https://{routerIP}/rest/ip/firewall/filter/:id
      params:
      - name: id
        value: '*1'
        type: path
        description: RouterOS internal record identifier
    docs: Remove a firewall filter rule.
  - info:
      name: List Firewall NAT Rules
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/firewall/nat
      params:
      - name: chain
        value: ''
        type: query
        description: Filter by chain (srcnat, dstnat)
    docs: Retrieve all firewall NAT rules.
  - info:
      name: Add Firewall NAT Rule
      type: http
    http:
      method: PUT
      url: https://{routerIP}/rest/ip/firewall/nat
      body:
        type: json
        data: '{}'
    docs: Add a new NAT rule.
  - info:
      name: List Firewall Address Lists
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/firewall/address-list
      params:
      - name: list
        value: ''
        type: query
        description: Filter by list name
    docs: Retrieve all firewall address list entries.
  - info:
      name: Add Firewall Address List Entry
      type: http
    http:
      method: PUT
      url: https://{routerIP}/rest/ip/firewall/address-list
      body:
        type: json
        data: '{}'
    docs: Add an IP address to a named address list.
- info:
    name: Routing
    type: folder
  items:
  - info:
      name: List Routes
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/route
      params:
      - name: dst-address
        value: ''
        type: query
        description: Filter by destination address
      - name: active
        value: ''
        type: query
        description: Filter by active routes
    docs: Retrieve the routing table.
  - info:
      name: Add Static Route
      type: http
    http:
      method: PUT
      url: https://{routerIP}/rest/ip/route
      body:
        type: json
        data: '{}'
    docs: Add a new static route.
- info:
    name: System
    type: folder
  items:
  - info:
      name: Get System Resources
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/system/resource
    docs: Retrieve system resource information including CPU load, memory usage, uptime, RouterOS version, and hardware details.
  - info:
      name: Get System Identity
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/system/identity
    docs: Retrieve the system hostname/identity.
  - info:
      name: Update System Identity
      type: http
    http:
      method: PATCH
      url: https://{routerIP}/rest/system/identity
      body:
        type: json
        data: '{}'
    docs: Update the system hostname.
  - info:
      name: List System Scripts
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/system/script
    docs: Retrieve all configured system scripts.
  - info:
      name: Add System Script
      type: http
    http:
      method: PUT
      url: https://{routerIP}/rest/system/script
      body:
        type: json
        data: '{}'
    docs: Create a new system script.
  - info:
      name: Run System Script
      type: http
    http:
      method: POST
      url: https://{routerIP}/rest/system/script/:id/run
      params:
      - name: id
        value: '*1'
        type: path
        description: RouterOS internal record identifier
    docs: Execute a specific system script.
- info:
    name: DHCP
    type: folder
  items:
  - info:
      name: List DHCP Servers
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/dhcp-server
    docs: Retrieve all DHCP server configurations.
  - info:
      name: List DHCP Leases
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/dhcp-server/lease
      params:
      - name: address
        value: ''
        type: query
        description: Filter by IP address
      - name: dynamic
        value: ''
        type: query
        description: Filter dynamic leases
    docs: Retrieve all DHCP leases including dynamic and static.
- info:
    name: DNS
    type: folder
  items:
  - info:
      name: Get DNS Settings
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/dns
    docs: Retrieve DNS cache settings and configuration.
  - info:
      name: Update DNS Settings
      type: http
    http:
      method: PATCH
      url: https://{routerIP}/rest/ip/dns
      body:
        type: json
        data: '{}'
    docs: Update DNS server configuration.
- info:
    name: Bridge
    type: folder
  items:
  - info:
      name: List Bridges
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/interface/bridge
    docs: Retrieve all bridge interface configurations.
  - info:
      name: Add Bridge
      type: http
    http:
      method: PUT
      url: https://{routerIP}/rest/interface/bridge
      body:
        type: json
        data: '{}'
    docs: Create a new bridge interface.
  - info:
      name: List Bridge Ports
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/interface/bridge/port
      params:
      - name: bridge
        value: ''
        type: query
        description: Filter by bridge interface name
    docs: Retrieve all bridge port configurations.
- info:
    name: Wireless
    type: folder
  items:
  - info:
      name: List Wireless Interfaces
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/interface/wireless
    docs: Retrieve all wireless interface configurations.
  - info:
      name: List Wireless Clients
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/interface/wireless/registration-table
    docs: Retrieve all connected wireless clients from the registration table.
- info:
    name: VPN
    type: folder
  items:
  - info:
      name: List IPsec Policies
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/ipsec/policy
    docs: Retrieve all IPsec policy configurations.
  - info:
      name: List IPsec Peers
      type: http
    http:
      method: GET
      url: https://{routerIP}/rest/ip/ipsec/peer
    docs: Retrieve all IPsec peer configurations.
bundled: true
