Flowable

Flowable connects systems, data, and people for faster and smarter process automation, drawing on a long heritage of open source BPM. Flowable provides a model-driven, low-code platform for end-to-end automation of BPMN, CMMN, and DMN processes, delivered through a programmatic Java Process Engine API and a packaged REST API. The Process Engine exposes RepositoryService, RuntimeService, TaskService, IdentityService, HistoryService, ManagementService, FormService, and DynamicBpmnService for managing process definitions, instances, tasks, history, and runtime behavior.

2 APIs 0 Features

AutomationBPMBPMNBusiness ProcessCMMNDMNWorkflows

GitHubOrganization

Sources

opencollection: 1.0.0
info:
  name: Flowable REST API
  version: 1.0.0
items:
- info:
    name: Deployments
    type: folder
  items:
  - info:
      name: List deployments
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/repository/deployments
    docs: List deployments
  - info:
      name: Create a deployment
      type: http
    http:
      method: POST
      url: https://flowable.example.com/flowable-rest/service/repository/deployments
      body:
        type: multipart-form
        data: []
    docs: Create a deployment
  - info:
      name: Get a deployment
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/repository/deployments/:deploymentId
      params:
      - name: deploymentId
        value: ''
        type: path
    docs: Get a deployment
  - info:
      name: Delete a deployment
      type: http
    http:
      method: DELETE
      url: https://flowable.example.com/flowable-rest/service/repository/deployments/:deploymentId
      params:
      - name: deploymentId
        value: ''
        type: path
    docs: Delete a deployment
  - info:
      name: List deployment resources
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/repository/deployments/:deploymentId/resources
      params:
      - name: deploymentId
        value: ''
        type: path
    docs: List deployment resources
- info:
    name: ProcessDefinitions
    type: folder
  items:
  - info:
      name: List process definitions
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/repository/process-definitions
    docs: List process definitions
  - info:
      name: Get a process definition
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/repository/process-definitions/:processDefinitionId
      params:
      - name: processDefinitionId
        value: ''
        type: path
    docs: Get a process definition
  - info:
      name: Update process definition (e.g. category, suspend/activate)
      type: http
    http:
      method: PUT
      url: https://flowable.example.com/flowable-rest/service/repository/process-definitions/:processDefinitionId
      params:
      - name: processDefinitionId
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Update process definition (e.g. category, suspend/activate)
- info:
    name: Models
    type: folder
  items:
  - info:
      name: List models
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/repository/models
    docs: List models
  - info:
      name: Create a model
      type: http
    http:
      method: POST
      url: https://flowable.example.com/flowable-rest/service/repository/models
      body:
        type: json
        data: '{}'
    docs: Create a model
- info:
    name: ProcessInstances
    type: folder
  items:
  - info:
      name: List process instances
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/runtime/process-instances
    docs: List process instances
  - info:
      name: Start a process instance
      type: http
    http:
      method: POST
      url: https://flowable.example.com/flowable-rest/service/runtime/process-instances
      body:
        type: json
        data: '{}'
    docs: Start a process instance
- info:
    name: Tasks
    type: folder
  items:
  - info:
      name: List tasks
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/runtime/tasks
    docs: List tasks
  - info:
      name: Get a task
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/runtime/tasks/:taskId
      params:
      - name: taskId
        value: ''
        type: path
    docs: Get a task
  - info:
      name: Perform a task action (claim, complete, delegate, resolve)
      type: http
    http:
      method: POST
      url: https://flowable.example.com/flowable-rest/service/runtime/tasks/:taskId
      params:
      - name: taskId
        value: ''
        type: path
      body:
        type: json
        data: '{}'
    docs: Perform a task action (claim, complete, delegate, resolve)
- info:
    name: CMMN
    type: folder
  items:
  - info:
      name: List CMMN case instances
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/cmmn-runtime/case-instances
    docs: List CMMN case instances
  - info:
      name: Start a CMMN case instance
      type: http
    http:
      method: POST
      url: https://flowable.example.com/flowable-rest/service/cmmn-runtime/case-instances
      body:
        type: json
        data: '{}'
    docs: Start a CMMN case instance
  - info:
      name: Delete a CMMN case instance
      type: http
    http:
      method: DELETE
      url: https://flowable.example.com/flowable-rest/service/cmmn-runtime/case-instances/:caseInstanceId
      params:
      - name: caseInstanceId
        value: ''
        type: path
    docs: Delete a CMMN case instance
  - info:
      name: List DMN decision tables
      type: http
    http:
      method: GET
      url: https://flowable.example.com/flowable-rest/service/dmn-repository/decision-tables
    docs: List DMN decision tables
  - info:
      name: Execute a DMN decision
      type: http
    http:
      method: POST
      url: https://flowable.example.com/flowable-rest/service/dmn-rule/execute
      body:
        type: json
        data: '{}'
    docs: Execute a DMN decision
bundled: true
