Matrix

Matrix is an open standard and decentralized protocol for real-time communication, providing federated messaging, voice, video, and IoT signalling across independently operated homeservers. The Matrix specification defines several REST APIs (Client-Server, Server-Server, Application Service, Identity Service, and Push Gateway) that interoperate across the federation. Authentication is typically performed via Bearer access tokens, with newer flows using OAuth 2.0.

5 APIs 0 Features

MessagingDecentralizedFederatedOpen StandardReal-Time CommunicationVoIP

APIs

Matrix Client-Server API

REST API used by Matrix clients to communicate with a homeserver, covering login, room creation and management, message sending, sync, device management, end-to-end encryption, ...

Matrix Server-Server (Federation) API

Federation API that lets Matrix homeservers exchange events, presence, and key information with one another over signed JSON requests.

Matrix Application Service API

API used by application services (bridges, bots) to integrate with a homeserver, claim namespaces, and exchange events.

Matrix Identity Service API

API for looking up Matrix user IDs from third-party identifiers such as email addresses and phone numbers via federated identity servers.

Matrix Push Gateway API

Push Gateway API homeservers use to deliver notifications to mobile push services on behalf of Matrix clients.

Collections

Matrix Client-Server API

OPEN

Event Specifications

Matrix Client-Server Sync API

AsyncAPI description of the Matrix Client-Server sync mechanism. Matrix delivers real-time events to clients through the `/_matrix/client/v3/sync` endpoint, which is a long-live...

ASYNCAPI

Resources

Specification Repository

Specification Repository

👥

GitHubOrganization

Sources

opencollection: 1.0.0
info:
  name: Matrix Client-Server API
  version: v3
request:
  auth:
    type: bearer
    token: '{{bearerToken}}'
items:
- info:
    name: List supported login flows
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/login
  docs: List supported login flows
- info:
    name: Authenticate and obtain an access token
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/login
    body:
      type: json
      data: '{}'
  docs: Authenticate and obtain an access token
- info:
    name: Invalidate the current access token
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/logout
  docs: Invalidate the current access token
- info:
    name: Refresh an access token
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/refresh
    body:
      type: json
      data: '{}'
  docs: Refresh an access token
- info:
    name: Register a new user account
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/register
    params:
    - name: kind
      value: ''
      type: query
    body:
      type: json
      data: '{}'
  docs: Register a new user account
- info:
    name: Get the current user ID
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/account/whoami
  docs: Get the current user ID
- info:
    name: Query server capabilities
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/capabilities
  docs: Query server capabilities
- info:
    name: Synchronize client state with the server
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/sync
    params:
    - name: since
      value: ''
      type: query
    - name: timeout
      value: ''
      type: query
    - name: full_state
      value: ''
      type: query
    - name: set_presence
      value: ''
      type: query
    - name: filter
      value: ''
      type: query
  docs: Synchronize client state with the server
- info:
    name: Create a new room
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/createRoom
    body:
      type: json
      data: '{}'
  docs: Create a new room
- info:
    name: Join a room by ID or alias
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/join/:roomIdOrAlias
    params:
    - name: roomIdOrAlias
      value: ''
      type: path
  docs: Join a room by ID or alias
- info:
    name: Leave a room
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/rooms/:roomId/leave
    params:
    - name: roomId
      value: ''
      type: path
  docs: Leave a room
- info:
    name: Invite a user to a room
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/rooms/:roomId/invite
    params:
    - name: roomId
      value: ''
      type: path
    body:
      type: json
      data: '{}'
  docs: Invite a user to a room
- info:
    name: Send a message event to a room
    type: http
  http:
    method: PUT
    url: https://{homeserver}/_matrix/client/v3/rooms/:roomId/send/:eventType/:txnId
    params:
    - name: roomId
      value: ''
      type: path
    - name: eventType
      value: ''
      type: path
    - name: txnId
      value: ''
      type: path
    body:
      type: json
      data: '{}'
  docs: Send a message event to a room
- info:
    name: Get message history for a room
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/rooms/:roomId/messages
    params:
    - name: roomId
      value: ''
      type: path
    - name: from
      value: ''
      type: query
    - name: to
      value: ''
      type: query
    - name: dir
      value: ''
      type: query
    - name: limit
      value: ''
      type: query
    - name: filter
      value: ''
      type: query
  docs: Get message history for a room
- info:
    name: Look up a room ID by alias
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/directory/room/:roomAlias
    params:
    - name: roomAlias
      value: ''
      type: path
  docs: Look up a room ID by alias
- info:
    name: List public rooms in the homeserver directory
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/publicRooms
  docs: List public rooms in the homeserver directory
- info:
    name: Retrieve a user profile
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/profile/:userId
    params:
    - name: userId
      value: ''
      type: path
  docs: Retrieve a user profile
- info:
    name: Set a profile field (display name or avatar URL)
    type: http
  http:
    method: PUT
    url: https://{homeserver}/_matrix/client/v3/profile/:userId/:keyName
    params:
    - name: userId
      value: ''
      type: path
    - name: keyName
      value: ''
      type: path
    body:
      type: json
      data: '{}'
  docs: Set a profile field (display name or avatar URL)
- info:
    name: List the current user's devices
    type: http
  http:
    method: GET
    url: https://{homeserver}/_matrix/client/v3/devices
  docs: List the current user's devices
- info:
    name: Upload end-to-end encryption keys
    type: http
  http:
    method: POST
    url: https://{homeserver}/_matrix/client/v3/keys/upload
    body:
      type: json
      data: '{}'
  docs: Upload end-to-end encryption keys
bundled: true
