F5 Load Balancer

opencollection: 1.0.0
info:
  name: F5 Load Balancer F5 BIG-IP iControl REST API
  version: 15.1.0
request:
  auth:
    type: basic
    username: '{{username}}'
    password: '{{password}}'
items:
- info:
    name: Virtual Servers
    type: folder
  items:
  - info:
      name: F5 Load Balancer List all virtual servers
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/virtual
      params:
      - name: $select
        value: ''
        type: query
        description: Comma-separated list of properties to include in the response.
      - name: $filter
        value: ''
        type: query
        description: OData filter expression to restrict returned resources.
      - name: $top
        value: ''
        type: query
        description: Maximum number of resources to return.
      - name: $skip
        value: ''
        type: query
        description: Number of resources to skip before returning results.
      - name: expandSubcollections
        value: ''
        type: query
        description: When set to true, inline sub-collections in the response.
    docs: Retrieves a collection of all virtual server resources configured on the BIG-IP system. Returns virtual server properties
      including destination address, pool assignment, profiles, and operational state.
  - info:
      name: F5 Load Balancer Create a virtual server
      type: http
    http:
      method: POST
      url: https://{bigip_host}/mgmt/tm/ltm/virtual
      body:
        type: json
        data: '{}'
    docs: Creates a new virtual server resource on the BIG-IP system. The virtual server defines a traffic destination address
      and port to which the BIG-IP listens for client connections.
  - info:
      name: F5 Load Balancer Get a specific virtual server
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/virtual/:virtualName
      params:
      - name: virtualName
        value: ''
        type: path
        description: Name of the virtual server resource, optionally prefixed with the partition path (e.g., ~Common~my_virtual).
    docs: Retrieves a single virtual server resource identified by name, including all of its configuration properties and
      operational state.
  - info:
      name: F5 Load Balancer Update a virtual server
      type: http
    http:
      method: PUT
      url: https://{bigip_host}/mgmt/tm/ltm/virtual/:virtualName
      params:
      - name: virtualName
        value: ''
        type: path
        description: Name of the virtual server resource, optionally prefixed with the partition path (e.g., ~Common~my_virtual).
      body:
        type: json
        data: '{}'
    docs: Replaces the configuration of an existing virtual server resource. All writable properties should be included in
      the request body.
  - info:
      name: F5 Load Balancer Partially update a virtual server
      type: http
    http:
      method: PATCH
      url: https://{bigip_host}/mgmt/tm/ltm/virtual/:virtualName
      params:
      - name: virtualName
        value: ''
        type: path
        description: Name of the virtual server resource, optionally prefixed with the partition path (e.g., ~Common~my_virtual).
      body:
        type: json
        data: '{}'
    docs: Modifies specific properties of an existing virtual server without requiring the full resource representation.
  - info:
      name: F5 Load Balancer Delete a virtual server
      type: http
    http:
      method: DELETE
      url: https://{bigip_host}/mgmt/tm/ltm/virtual/:virtualName
      params:
      - name: virtualName
        value: ''
        type: path
        description: Name of the virtual server resource, optionally prefixed with the partition path (e.g., ~Common~my_virtual).
    docs: Removes a virtual server resource from the BIG-IP system. Existing connections may be disrupted depending on the
      virtual server state.
- info:
    name: Pools
    type: folder
  items:
  - info:
      name: F5 Load Balancer List all pools
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/pool
      params:
      - name: $select
        value: ''
        type: query
        description: Comma-separated list of properties to include in the response.
      - name: $filter
        value: ''
        type: query
        description: OData filter expression to restrict returned resources.
      - name: $top
        value: ''
        type: query
        description: Maximum number of resources to return.
      - name: $skip
        value: ''
        type: query
        description: Number of resources to skip before returning results.
      - name: expandSubcollections
        value: ''
        type: query
        description: When set to true, inline sub-collections in the response.
    docs: Retrieves a collection of all load balancing pool resources configured on the BIG-IP system. Pools contain members
      that receive traffic distributed by virtual servers.
  - info:
      name: F5 Load Balancer Create a pool
      type: http
    http:
      method: POST
      url: https://{bigip_host}/mgmt/tm/ltm/pool
      body:
        type: json
        data: '{}'
    docs: Creates a new load balancing pool on the BIG-IP system. A pool is a collection of backend server members to which
      the BIG-IP distributes client traffic.
  - info:
      name: F5 Load Balancer Get a specific pool
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/pool/:poolName
      params:
      - name: poolName
        value: ''
        type: path
        description: Name of the pool resource, optionally prefixed with the partition path (e.g., ~Common~my_pool).
    docs: Retrieves a single pool resource identified by name including its configuration and load balancing settings.
  - info:
      name: F5 Load Balancer Update a pool
      type: http
    http:
      method: PUT
      url: https://{bigip_host}/mgmt/tm/ltm/pool/:poolName
      params:
      - name: poolName
        value: ''
        type: path
        description: Name of the pool resource, optionally prefixed with the partition path (e.g., ~Common~my_pool).
      body:
        type: json
        data: '{}'
    docs: Replaces the configuration of an existing pool resource.
  - info:
      name: F5 Load Balancer Delete a pool
      type: http
    http:
      method: DELETE
      url: https://{bigip_host}/mgmt/tm/ltm/pool/:poolName
      params:
      - name: poolName
        value: ''
        type: path
        description: Name of the pool resource, optionally prefixed with the partition path (e.g., ~Common~my_pool).
    docs: Removes a pool resource from the BIG-IP system. Any virtual servers referencing this pool should be updated before
      deletion.
- info:
    name: Pool Members
    type: folder
  items:
  - info:
      name: F5 Load Balancer List pool members
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/pool/:poolName/members
      params:
      - name: poolName
        value: ''
        type: path
        description: Name of the pool resource, optionally prefixed with the partition path (e.g., ~Common~my_pool).
      - name: $select
        value: ''
        type: query
        description: Comma-separated list of properties to include in the response.
      - name: $filter
        value: ''
        type: query
        description: OData filter expression to restrict returned resources.
    docs: Retrieves a collection of all members within a specific pool including their addresses, ports, and operational states.
  - info:
      name: F5 Load Balancer Add a member to a pool
      type: http
    http:
      method: POST
      url: https://{bigip_host}/mgmt/tm/ltm/pool/:poolName/members
      params:
      - name: poolName
        value: ''
        type: path
        description: Name of the pool resource, optionally prefixed with the partition path (e.g., ~Common~my_pool).
      body:
        type: json
        data: '{}'
    docs: Adds a new server member to the specified pool. The member is identified by its node address and service port.
  - info:
      name: F5 Load Balancer Get a specific pool member
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/pool/:poolName/members/:memberName
      params:
      - name: poolName
        value: ''
        type: path
        description: Name of the pool resource, optionally prefixed with the partition path (e.g., ~Common~my_pool).
      - name: memberName
        value: ''
        type: path
        description: Name of the pool member in address:port format (e.g., ~Common~10.0.0.1:80).
    docs: Retrieves a single pool member resource including its configuration, health status, and statistics.
  - info:
      name: F5 Load Balancer Update a pool member
      type: http
    http:
      method: PUT
      url: https://{bigip_host}/mgmt/tm/ltm/pool/:poolName/members/:memberName
      params:
      - name: poolName
        value: ''
        type: path
        description: Name of the pool resource, optionally prefixed with the partition path (e.g., ~Common~my_pool).
      - name: memberName
        value: ''
        type: path
        description: Name of the pool member in address:port format (e.g., ~Common~10.0.0.1:80).
      body:
        type: json
        data: '{}'
    docs: Replaces the configuration of a specific pool member.
  - info:
      name: F5 Load Balancer Remove a pool member
      type: http
    http:
      method: DELETE
      url: https://{bigip_host}/mgmt/tm/ltm/pool/:poolName/members/:memberName
      params:
      - name: poolName
        value: ''
        type: path
        description: Name of the pool resource, optionally prefixed with the partition path (e.g., ~Common~my_pool).
      - name: memberName
        value: ''
        type: path
        description: Name of the pool member in address:port format (e.g., ~Common~10.0.0.1:80).
    docs: Removes a server member from the specified pool.
- info:
    name: Nodes
    type: folder
  items:
  - info:
      name: F5 Load Balancer List all nodes
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/node
      params:
      - name: $select
        value: ''
        type: query
        description: Comma-separated list of properties to include in the response.
      - name: $filter
        value: ''
        type: query
        description: OData filter expression to restrict returned resources.
      - name: $top
        value: ''
        type: query
        description: Maximum number of resources to return.
      - name: $skip
        value: ''
        type: query
        description: Number of resources to skip before returning results.
    docs: Retrieves a collection of all node resources on the BIG-IP system. Nodes represent backend servers identified by
      their IP addresses or FQDNs.
  - info:
      name: F5 Load Balancer Create a node
      type: http
    http:
      method: POST
      url: https://{bigip_host}/mgmt/tm/ltm/node
      body:
        type: json
        data: '{}'
    docs: Creates a new node resource representing a backend server on the network. Nodes are the foundation for pool members.
  - info:
      name: F5 Load Balancer Get a specific node
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/node/:nodeName
      params:
      - name: nodeName
        value: ''
        type: path
        description: Name of the node resource, optionally prefixed with the partition path.
    docs: Retrieves a single node resource including its address, monitoring status, and configuration.
  - info:
      name: F5 Load Balancer Update a node
      type: http
    http:
      method: PUT
      url: https://{bigip_host}/mgmt/tm/ltm/node/:nodeName
      params:
      - name: nodeName
        value: ''
        type: path
        description: Name of the node resource, optionally prefixed with the partition path.
      body:
        type: json
        data: '{}'
    docs: Replaces the configuration of an existing node resource.
  - info:
      name: F5 Load Balancer Delete a node
      type: http
    http:
      method: DELETE
      url: https://{bigip_host}/mgmt/tm/ltm/node/:nodeName
      params:
      - name: nodeName
        value: ''
        type: path
        description: Name of the node resource, optionally prefixed with the partition path.
    docs: Removes a node resource from the BIG-IP system. The node must not be referenced by any pool members.
- info:
    name: Monitors
    type: folder
  items:
  - info:
      name: F5 Load Balancer List HTTP health monitors
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/monitor/http
    docs: Retrieves all HTTP health monitors configured on the BIG-IP system. HTTP monitors verify availability by sending
      HTTP requests to pool members and evaluating the responses.
  - info:
      name: F5 Load Balancer Create an HTTP health monitor
      type: http
    http:
      method: POST
      url: https://{bigip_host}/mgmt/tm/ltm/monitor/http
      body:
        type: json
        data: '{}'
    docs: Creates a new HTTP health monitor that sends HTTP requests to pool members to verify their availability and responsiveness.
  - info:
      name: F5 Load Balancer List HTTPS health monitors
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/monitor/https
    docs: Retrieves all HTTPS health monitors configured on the BIG-IP system. HTTPS monitors verify availability over TLS-encrypted
      connections.
  - info:
      name: F5 Load Balancer List TCP health monitors
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/monitor/tcp
    docs: Retrieves all TCP health monitors configured on the BIG-IP system. TCP monitors verify that pool members are accepting
      connections on the specified port.
- info:
    name: Profiles
    type: folder
  items:
  - info:
      name: F5 Load Balancer List HTTP profiles
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/profile/http
    docs: Retrieves all HTTP traffic profiles on the BIG-IP system. HTTP profiles configure how the BIG-IP processes HTTP
      traffic including compression, caching, and header manipulation.
  - info:
      name: F5 Load Balancer List TCP profiles
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/profile/tcp
    docs: Retrieves all TCP traffic profiles on the BIG-IP system. TCP profiles optimize TCP connection behavior for different
      application and network scenarios.
  - info:
      name: F5 Load Balancer List client SSL profiles
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/profile/client-ssl
    docs: Retrieves all client-side SSL profiles on the BIG-IP system. Client SSL profiles manage TLS/SSL termination for
      connections between clients and the BIG-IP.
- info:
    name: Policies
    type: folder
  items:
  - info:
      name: F5 Load Balancer List local traffic policies
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/policy
    docs: Retrieves all local traffic policies on the BIG-IP system. Policies provide rule-based traffic steering, content
      manipulation, and request/response modification.
- info:
    name: iRules
    type: folder
  items:
  - info:
      name: F5 Load Balancer List iRules
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/rule
    docs: Retrieves all iRule resources on the BIG-IP system. iRules are Tcl-based scripts that provide custom traffic management
      logic for virtual servers.
- info:
    name: SSL Certificates
    type: folder
  items:
  - info:
      name: F5 Load Balancer List SSL certificates
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/sys/file/ssl-cert
    docs: Retrieves all SSL certificate files installed on the BIG-IP system that are available for use in SSL profiles.
- info:
    name: Data Groups
    type: folder
  items:
  - info:
      name: F5 Load Balancer List internal data groups
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/data-group/internal
    docs: Retrieves all internal data groups on the BIG-IP system. Data groups provide address, string, and integer lookups
      used in iRules and traffic policies for decision-making.
- info:
    name: SNAT Pools
    type: folder
  items:
  - info:
      name: F5 Load Balancer List SNAT pools
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/ltm/snatpool
    docs: Retrieves all SNAT pool resources on the BIG-IP system. SNAT pools define collections of translation addresses used
      for outbound connection source address translation.
- info:
    name: System
    type: folder
  items:
  - info:
      name: F5 Load Balancer Get system information
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/sys
    docs: Retrieves top-level system information and available sub-collections for the BIG-IP system.
  - info:
      name: F5 Load Balancer Get system software version
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/sys/version
    docs: Retrieves the software version information for the BIG-IP system including product name, version, build number,
      and edition.
  - info:
      name: F5 Load Balancer List BIG-IP devices
      type: http
    http:
      method: GET
      url: https://{bigip_host}/mgmt/tm/sys/device
    docs: Retrieves information about all BIG-IP devices in the device trust group, including hostname, management address,
      failover state, and device group membership.
bundled: true
